Description
The RS V2 lineup is our new and improved entry level model. This lineup boasts its new soft parts and motor showing increases of up to 43% in BL and over a 100% increase in BL^2/Re in some models. Power handling has also increased ranging from 500RMS on the 8” up to 750RMS on the 12” and 15”
| SPECS | RS 12 V2 | |
| RMS | 750 | |
| Voice Coil | 3″ | |
| Impedance | Dual 4 Ohm | |
| SPL | 85.7 dB | |
| FS | 31.140 Hz | |
| BL | 28.793 | |
| RE (Ohms) | 7.6 | |
| QMS | 3.023 | |
| QES | 0.483 | |
| QTS | 0.416 | |
| CMS (uM/N) | 0.097 | |
| MMS | 269.274 g | |
| VAS | 38.831 L |
BOX SPECS
Every vehicles applications, equipment, tuning, wiring, ext all play a factor in making sure your woofers are playing clean signals to avoid any clipping. Our products have the reputation of taking some of the most abuse in the industry for its given power rating, but to ensure the longevity using the right air space and scoping for a clean signal will be sure to have a lasting daily resilient subwoofer.
Suggested Healthy spec range.
Rule of thumb lean towards smaller enclousre if clamping @ or more than conservative power. Lean towards bigger enclosure clamping below conservative power
| CUBIC FT | 1.5 – 2.25 CUBIC FT PER SUBWOOFER |
| TUNING | 28-32HERTZ |
| PORT AREA | 12-16 SQ INCHES OF PORT AREA PER CUBIC FT |
| MOUNTING DEPTH | 6.75 INCHES |
| CUTOUT | 11.14 INCHES |
