Description
The RS V2 lineup is our new and improved entry level model. This lineup boasts its new soft parts and motor showing increases of up to 43% in BL and over a 100% increase in BL^2/Re in some models. Power handling has also increased ranging from 500RMS on the 8” up to 750RMS on the 12” and 15”
| SPECS | RS 15 V2 |
| RMS | 750 |
| Voice Coil | 3″ |
| Impedance | Dual 4 Ohm |
| SPL | 89.7 dB |
| FS | 28.48 Hz |
| BL | 30.095 |
| RE (Ohms) | 7.6 |
| QMS | 4.093 |
| QES | 0.417 |
| QTS | 0.378 |
| CMS (uM/N) | 0.11 |
| MMS | 277.43g |
| VAS | 109.999 |
BOX SPECS
| CUBIC FT | 3-4 CUBIC FT PER SUBWOOFER |
| TUNING | 29-34HERTZ |
| PORT AREA | 12-16 SQ INCHES OF PORT AREA PER CUBIC FT |
| MOUNTING DEPTH | 7 7/8 INCHES |
| CUTOUT | 13.9 INCHES |
