Description
| Nominal Impedance | 8 ohms |
| AES Power Handling | 160W |
| Program Power Handling | 320W |
| Peak Power handling | 640W |
| Sensitivity (1w/1m) With Horn | 114dB |
| Frequency Response | 630Hz-20KHz |
| Recommended Hi Pass Crossover | 900Hz |
| Sold in Pair or Single | Single |
MOTOR
| Voice Coil Diameter | 2” / 51.5mm |
| Voice Coil Former Material | Kapton |
| Winding Material LITTIE | CCA |
| Diaphragm Material | Titanium |
| Magnet Material | Ferrite |
| Magnet Weight | 35 Oz |
| Body Material | Aluminum |
HORN SPECIFICATIONS
| Nominal Diameter | 6.5” / 165mm |
| Throat Diameter | 2” / 50.8mm |
| Sound Coverage | 57” Rounded |
| Body Material | Aluminum |
| Color/Finish | Black / Satin |
MEASUREMENT
| Overall Diameter | 6.14” / 165mm |
| Overall Depth | 2” / 50.8mm |
| Mounting Depth | 57” Rounded |
| Mounting Hole Diameter | 5.7” / 145mm |
| Bolt Pattern (Horn) | ø 6.33” / 161mm x 4 – 0.21” / 5.5mm Hole |
