Description
Product Overview
Engineered for high-efficiency sound in space-restricted environments, the Beyma PRO5Q200Nd delivers massive pro-audio performance from a compact 5-inch footprint. Powered by a lightweight, ultra-dense neodymium motor, this driver combines high thermal power handling with impressive sensitivity and linear excursion.
Whether you are upgrading a motorcycle audio system, outfitting a powersports vehicle, or building custom door panels, the PRO5Q200Nd brings crisp, articulate midbass punch and wideband clarity without burdening your setup with extra weight.
Key Features
- Neodymium Motor StructurePremium neodymium magnet design minimizes depth and physical weight while delivering superior motor strength and sensitivity.
- High Output & EfficiencyWith 92 dB sensitivity and 150W AES power handling, it produces exceptionally loud, clean sound across the midbass and midrange spectrum.
- Extended Cone DisplacementA 5.7 mm linear Xmax allows for substantial low-end stroke, keeping midbass tight and punchy even at high volume levels.
- Wide Frequency ResponseCovers a broad spectrum from 70 Hz up to 10 kHz, making crossover integration seamless.
- 4-Ohm ImpedanceOptimized to draw maximum power from standard mobile and marine amplifiers.
- Built for Tight SpacesCompact chassis design specifically tailored for custom fairings, pods, and tight mounting locations.
Technical Data
| Specification | Details |
|---|---|
| Impedance | 4 Ohms |
| Sensitivity | 92 dB |
| Nominal Diameter | 5 Inches (125 mm) |
| Nominal Impedance | 4 Ohms |
| AES Power Handling | 150 Watts |
| Program Power Handling | 300 Watts |
| Sensitivity (1W / 1m) | 92 dB |
| Frequency Range | 70 Hz – 10,000 Hz |
| Voice Coil Diameter | 1.5 Inches (38.1 mm) |
| Peak-to-Peak Excursion ( $X_{max}$ ) | 5.7 mm |
| Magnet Type | High-Grade Neodymium |
Fitment & Applications
- Motorcycle AudioHD fairings, saddlebag lids, and lowers requiring high output under road noise.
- Powersports & UTVsLightweight performance audio for side-by-sides, ATVs, and marine installations.
- Custom Car AudioHigh-output door panels, kick pods, and active 3-way setups.
Tuning TipNote: For optimal performance and driver protection, use with an appropriately tuned high-pass crossover filter and a dedicated rear chamber or enclosure.
