Description
Product Overview
Bring razor-sharp high-frequency detail and extreme volume to your audio system with the Galeforce Audio T25 Super Tweeter . Engineered for pro-audio setups, high-output car audio door panels, motorcycle fairings, and powersports builds, the T25 delivers ultra-crisp highs designed to slice through heavy midbass, subwoofers, and open-road noise.
Built around a premium titanium diaphragm and a lightweight Copper-Clad Aluminum Wire (CCAW) 1-inch voice coil, this bullet tweeter boasts a massive 104 dB sensitivity rating . That means it converts amplifier power into intense, distortion-free top-end energy with ease. Sold individually, the T25 is the perfect high-frequency solution when standard dome tweeters just can’t keep up.
Key Features
- Extreme Efficiency (104 dB SPL)Produces screaming high-frequency output with minimal amplifier power.
- Titanium DiaphragmUltra-stiff diaphragm delivers brilliant, precise top-end detail without breaking down under high SPL levels.
- CCAW Voice Coil1-inch Copper-Clad Aluminum Wire voice coil on a KSV former ensures fast thermal dissipation and lightweight motion.
- 3 kHz – 20 kHz Frequency ResponsePurpose-built for pure upper-frequency sparkle, handoffs, and vocal detail.
- Compact Bullet DesignCompact aluminum chassis with a 2.65″ mounting depth for easy integration into custom A-pillars, door pods, and fairings.
Technical Data
| Specification | Details |
|---|---|
| Size | 65 inch |
| Sensitivity | 104 dB |
| Frequency Response | 3 kHz – 20 kHz |
| Mounting Depth | 2.65 Inches (67.5 mm) |
| Tweeter Type | Super Bullet Tweeter |
| Nominal Impedance | 4 Ohms |
| AES Power Handling | 35 Watts (above 800 Hz) / 45 Watts (above 1.5 kHz) |
| Program Power Handling | 75 Watts (above 800 Hz) / 95 Watts (above 1.5 kHz) |
| Sensitivity (1W / 1m) | 104 dB |
| Frequency Range | 3,000 Hz – 20,000 Hz |
| Voice Coil Diameter | 1.0 Inch (25.4 mm) CCAW |
| Diaphragm Material | Titanium |
| Overall Diameter | 2.28 Inches (58 mm) |
| Quantity | Sold Individually |
Fitment & Applications
- Pro-Audio Car Door PanelsHigh-output front stages needing a dedicated bullet tweeter to balance heavy 6.5″ or 8″ midranges.
- Motorcycle AudioCustom fairing, gauge-pod, or bagger setups designed to cut through high-speed wind and pipe noise.
- Powersports & MarineHigh-efficiency top-end reinforcement for side-by-side pods and boat sound towers.
Tuning TipSystem Tuning & Crossover Note: High-compression super tweeters must be properly filtered to prevent damage from lower frequencies. Always use an active High-Pass Filter (HPF) set at or above 3,500 Hz to 4,000 Hz (12 dB or 24 dB slope) or inline crossover capacitor.
