Description
Product Overview
Add detail to any speaker with PRV Audio’s TW700Ti-4 SLIM titanium PRO Audio bullet super tweeter!
This tweeter is Slim version of our famous, powerful TW700ti. The new design features a Slim magnet and throat, making it the perfect Pro Audio On Wheels ® tweeter for your car audio application.
4-inch square high compression PRO bullet tweeter features flat sides allow for close side by side mounting. With high frequency response up to 20,000 Hz and a sensitivity of 105 dB at 1W/1m, the TW700Ti-4 SLIM can keep up with your custom door speaker system.
High Frequency Bullet Tweeter, capable of adding brilliance and articulation to any professional loudspeaker system.
GENERAL SPECIFICATIONS
*Nominal power handling is defined as the maximum RMS power that the speaker can handle in a 2-hour test with a pink noise with 6dB of crest factor and a bandpass filter with 12db/oct tuned in its usable frequency range. **Continuous Program Power (RMS) is the maximum power that the speaker can handle considering a regular musical program using our recommended filters, this power can be used to define the optimum amplifier power to provide a clean signal without clipping or saturation. ***Max Peak Power is the maximum power operation for the speaker, this power is allowed just for a few fractions of a second, usually found just on the peaks of the music. Keeping this power for a little longer timer will damage the speaker.
EXTRA INFO
Technical Data
| Specification | Details |
|---|---|
| Size | 4 inch |
| Impedance | 4 Ohms |
| Sensitivity | 105 dB |
| Nominal impedance | 4 Ohms |
| Rated AES Power Handling (RMS) | 100 Watts |
| Program Power | 200 Watts |
| Sensitivity 2.00V at 1m | 105 dB |
| Recommended Hi Pass Crossover** **For Full Power Handling | 5000 Hz** **12db Per Octave Crossover |
| Frequency Response at -10dB | 4,500 – 20,000 Hz |
| Voice Coil Diameter | 1.5” (38 mm) |
| Voice Coil Wire | CCAW |
| Voice Coil Former Material | Kapton |
| Diaphragm Material | Aluminum |
| Flux Density | 1.50 T |
| Magnet Material | Ferrite |
