01 Overview
The details
Product Overview
The newly redesigned NXL-8TPNEO tower speakers are louder and stronger than ever! The pod contains the same speaker and driver combo that everyone loves from the previous generation but now the clamping system has been reinforced for stronger grip and protection all around. Also to improve loudness and sound quality, we have added a passive woofer radiator for even more bass response. RGB lighting is also included so you can match colors to your mood or color scheme.
Highlights
Technical Details Download CF-X8TPNEO Product Manual
02 Tech specs
By the numbers
RMS Power 01
180W
Continuous rating
Peak Power 02
550W
Short-burst rating
Sensitivity 03
95dB
Efficiency
Size 04
8in
Nominal
- RMS Power
- 180 Watts RMS
- Nominal Impedance
- 4 Ohms
- RMS Power Handling
- 180W
- MAX Power Handling
- 550W
- Crossover
- 12dB with Over Power Protection
- Frequency Response
- 60Hz – 21KHz
- Sensitivity (1w/1m)
- 95dB
- Excursion (one way)
- Xmax – 3mm
- Free Air Resonance
- Fs- 62Hz
- Enclosure Material
- Injection PC+ABS
- Voice Coil Diameter
- 1″
- Cone Material
- Waterproof Compress Paper + Carbon Fiber
- Surround Material
- Soft PC Damping Glued
- Basket Material
- PC Injection Molded Composite
- Magnet Material
- Neodymium
- Magnet Grade
- N40H
- Diaphragm Material
- PEN
- Size
- 8 inch
- Nominal Diameter
- 8”
- Equivalent Volume
- Vas – 17.5L
- Overall Diameter
- 8.59″ / 218.1mm
- Overall Depth
- 13.89″ / 352.9mm
- Overall Height
- 12.37″ / 314.3mm
- Marine Grade Type
- IP65 + UV Stable
- RGB LED
- Integrated LED-RGB Speaker Lighting Integrated LED-RGB Acrylic Ring Lighting 6 Core Wires for Lighting and Speaker
- Grill Type
- ABS+316 Stainless Metal Mesh
- Pair
- Yes
- Clamps
- Die-Cast adjustable (1″ ~ 2″) 360 Degree Rotation Mounting Buried Wire or Open Wire Mounting Optional, Included NBR Pad And Stainless Hardware (Screws,Stop Washers,Hexagon wrench, Safety Rope, Screw fastening Glue)
- Front Logo
- Yes, Can be Rotated For Correct Angle Display
- Passive Radiator
- 4″ With LED RGB Light
- Type
- Compression Driver with CNC Solid Aluminum Horn
- Total Factor
- Qts – 0.756
