Description
Product Overview
Having the perfect tools to make your sound system the ultimate music machine is what DS18 has for you. Our crossovers are designed to provide the perfect frequency distribution throughout your system to ensure the clarity and peak efficiency for your acoustic needs. This EQ has 7 separate bands including bass and are adjusted in real time while sitting in your vehicle and on the fly with just a twist of your fingers. The included hi-lo converter also makes it the perfect choice for those looking to add amplifiers to their factory radio.
Highlights
Technical Details EQX7 Product Manual
Technical Data
| Specification | Details |
|---|---|
| Frequency Response | 10Hz-50KHz +/-1dB |
| Model | EQX7 |
| Boost / Cut | 12dB |
| S/N ratio | 100dB |
| Maximum Output voltage | 8V |
| THD | 0.005% |
| Input impedance | 20K Ohms |
| Head Room | 20 dB |
| Output impedance | 2K Ohms |
| Stereo Separation | 82 dB/1 KHz |
| Operating voltage | 11V-15V Negative Ground |
| Dimension(L x W x H) | 7″ x 4.40″ x 1.18″ |
