Description
Product Overview
High excursion is now the standard in all big bass applications and we want to bring the experience of low frequency bass and high power to every user at a great price point. The EXL-XX15.4DHE is the answer to that. This subwoofer is a high addition that comes in at an amazing price point while getting all those features other much more expensive high excursion subs come with. Also, with a power rating of 2000w RMS and 4000w Max, with the right power this sub will have increased excursion, decibels, and loudness altogether for a real competition bass experience.
Highlights
Technical Details EXL-XX15.4DHE Product Manual
Box Info
Box Info
Technical Data
| Specification | Details |
|---|---|
| Size | 15 inch |
| RMS Power | 2000 Watts RMS |
| Peak Power | 4000 Watts Max |
| Impedance | 4 Ohms |
| Frequency Response | 20Hz – 1.5KHz |
| Mounting Depth | 8.86″ / 225mm |
| Nominal Diameter | 15 |
| Nominal Impedance | 4 + 4 Ohms |
| RMS Power Handling | 2000W |
| MAX Power Handling | 4000W |
| Sensitivity (1w/1m) | 88 dB |
| Recommended Lo Pass Crossover | 80 Hz |
| VC Diameter | 3″ / 75.6mm |
| VC Former Material | Black Aluminum |
| Winding Material | CCAW |
| Cone Material | Paper |
| Dust Cap Material | Glass Fiber |
| Surround Material | Foam |
| Basket Material | Aluminum |
| Basket Color/Finish | Black |
| Magnet Material | Ferrite |
| Magnet Weight | 306 Oz |
| Displacement Volume | 3.26L |
| Equivalent Vol | Vas 29.965L |
| Excursion(one way) | Xmax 42 mm |
| Free Air Resonance | Fs 35.6 Hz |
| Mechanical Factor | Qms 7.098 |
| Electrical Factor | Qes 0.68 |
| Total Factor | Qts 0.62 |
| Moving Mass | Mms 410.638 g |
| Compliance | Cms 0.027 mm/N |
| Bl Factor | BL 19.865 |
| VC Inductance | Le 11.25 mH |
| Diaphragm Area | Sd 804.25 cm² |
| Dc Resistance | Re 3.6 + 3.6 ohms |
| Efficiency Bandwidth Product | EBP 52.3 |
| Overall Diameter | 15.59″ / 396mm |
| Overall Depth | 10.24″ / 260mm |
| Front Mount Baffle Cutout | 13.98″ / 355mm |
| Motor Diameter | 8.86″ / 225mm |
