Product Overview
The Gen-X series has always been a DS18 staple with the public and been in countless system builds over the many years it was released.
We have completely redesigned the GEN-X series from the ground up to meet and audio enthusiasts high standards and complete their goals for the system of their dreams with great power, reliability, and efficiency.
The G1800.4D has a power rating of 4 x 150 watts RMS at 4 ohms 4 x 230 watts RMS at 2 ohms, 2 x 430 watts at 4 ohm bridge, and 1800 watts MAX at the ohm load it was designed for, giving you pure and clean power on demand.
This amp has the power to drive your speakers but also not take up much space because of the new compact design and technology that will keep your amp playing cool and loud.
Highlights
Key Features
Great For:
Technical Details Download Product Manual
By the numbers
- Channels
- 4 Channel
- Amplifier Class
- Digital (D)
- RMS Power
- 920W (4 x 230W @ 2 ohm)
- Peak Power
- 1800 Watts Max
- Impedance
- 4 Ohms
- Total Watts (Peak)
- 1800W
- RMS Power @ 4 ohm
- 4 x 150W
- RMS Power @ 2 ohm
- 4 x 230W
- RMS Power @ 4 ohm Bridge
- 2 x 430W
- Damping Factor
- 78
- Input Impedance
- 22K
- Channel Separation
- 70dB
- Low Level Input Range
- 0.25-6V
- High Level Input
- NO
- X-Over Filter Range
- 50Hz-250Hz
- Bass Boost Range
- N/A
- Infrasonic Filter
- N/A
- Number of Channels
- 4CH
- Minimum Impedance
- 2 ohm St / 4 ohm Bridge
- Power Input Terminal Size
- 4 ga
- Fuse Size
- 2 X 40A
- DC Output Protection
- YES
- Short Circuit Output Protection
- YES
- Voltage Input Protection
- YES
- Frequency Response
- 20Hz-20KHz
- Efficiency @ 4ohm
- 81%
- Total Harmonic Distortion (THD)
- 0.01%
- Bass Boost Frequency
- N/A
- Body Color / Finish
- Matte black
- Overall Length
- 10.43″ / 265mm
- Overall Height
- 1.96″ / 50mm
- Heatsink Length
- 8.58″ / 218mm
- Gross Single Unit Weight
- 1.6KG
- Signal to Noise Ratio
- >90dB
- Selectable X-Over
- LPF/FLAT/HPF
- Phase Selector
- NO
- Amplifier Type
- 4CH Full Range
- Led Indicator
- Power / Protection / Clip
- Remote Level Control
- NO
- Cooling Fan
- NO
- Voltmeter
- NO
- Thermal Protection
- YES
- Over-Load Protection
- YES
- Clipping Protection
- YES
- Overall Wide
- 4.72″ / 120mm
