DS18 HOOL-X12.4DHE HOOLIGAN X 12″ High Excursion Subwoofer 4000 Watts Rms 4″ DVC 4-Ohm

$799.95

Lease for as low as $36.15/week. Apply Now

RMS Power4,000W
Peak Power6,000W
Xmax59mm
SKU: HOOL-X12.4DHE Categories: , , , Brand:
01 Overview

The details

Product Overview

Why we stock the DS18 HOOL-X12.4DHE

The DS18 HOOL-X12.4DHE is a 12″ Hooligan X high-excursion subwoofer with a 4″ dual 4 ohm voice coil. It handles 4,000 watts RMS (6,000 max) with 87 dB sensitivity and plays down to 20Hz.

Dual 4 ohm coils make it easy to run several subs on one amp. Need lower impedance? See the HOOL-X12.2DHE. Want a 15? Look at the HOOL-X15.4DHE.

The DS18 Hooligan X12 has already been proven to provide top end performance and bass now for multiple years on the streets and in the lanes, hooligans have been a choice of music lovers and competitors alike.

We have taken the Traditional Hooligan and revamped it in our newest revision, the Hooligan X12 High Excursion subwoofer. This model features long throw pole, larger spider, and high excursion surround to lower the FS of the speaker making it louder at subsonic frequencies. This massive sub will be great for high powered music or SPL. A FS of 26 will ensure deep lows down to 20hz and great punchy bass up around 40hz depending on your box tuning. This subwoofer is rated at 4000w RMS and 6000w max so your vehicle will require electrical upgrades and large wire.

This sub will be friendly to 4th orders, 6th orders, ported boxes, and large sealed boxes and can be used in most applications that has room for the box. With a 59mm one way XMAX, this sub is sure to pump out extreme decibils with the proper power and box setup. We recommend a tuning of 25-35hz for ported boxes depending on your goals.

If you are looking for extreme bass and massive power look no further than the Hooligan High Excursion line! This Hooligan variant will be sure to start you on your way to high volume hairtricks and massive lows!

Highlights

Technical Details HOOL-X12.4DHE Product Manual

02 Tech specs

By the numbers

HOOL-X12.4DHE · Manufacturer rated
RMS Power 01
4,000W
Continuous rating
Peak Power 02
6,000W
Short-burst rating
Xmax 03
59mm
One-way excursion
Sensitivity 04
87dB
Efficiency

Excursion

Scale 0 to 68mm

RMS Power
4000 Watts RMS
Peak Power
6000 Watts Max
Impedance
4 Ohms
Nominal Impedance
4+4 OHMS
RMS Power Handling
4000 WATTS
MAX Power Handling
6000 WATTS
Recommended Lo Pass Crossover
80 Hz

Frequency Response
20Hz – 500Hz
Sensitivity (1w/1m )
87 dB
Excursion (one way)
50 mm
Free Air Resonance
26 Hz
Bl Factor
23.86
Efficiency Bandwidth Product
49.2
Sealed Box Output Response
41 Hz
Port Tunning Frequency
30 Hz
Ported Box Output Response
25 Hz
Xmax
59 mm

Voice Coil Diameter
4” / 99.8 mm
Voice Coil Former Material
Black Aluminum
Winding Material
CCAW
Cone Material
Non Pressed Paper
Dust Cap Material
Carbon Fiber
Surround Material
Foam
Basket Material
Aluminum
Basket Color | Finish
Glossy Black with Machined Aluminum
Magnet Material
Ferrite
Magnet Weight
500 Oz
Voice Coil Inductance
42.15 mH
Motor Diameter
9.96″

Size
12 inch
Mounting Depth
10”
Nominal Diameter
12″ / 304.8 mm
Displacement Volume
4.8L / 0.169ft3
Equivalent Volume
21.86 L / 0.77 ft3
Sealed Internal Volume
17L / 0.6 ft3
Ported Internal Volume
42.5L / 1.5 ft3
Port Size *Square (WxHxL)
1.52″ x 12.28″ x 31.82″
Overall Diameter
12.64”
Overall Depth
11.6”
Front Mount Baffle Cutout
11.2”

Mechanical Factor
2.75
Electrical Factor
0.528
Total Factor
0.517
Moving Mass
486.45 g
Compliance
0.074 mm/N
Diaphragm Area
471.44 cm2
DC Resistance
3.2+3.2 OHM
