Product Overview
DS18 Infinite AGM power-cell batteries are what real enthusiasts need for all their charging system needs. These batteries have been proven tough and able to withstand extreme amperage draws and hold strong voltage through the most demanding of times. This AGM (absorbed glass mat) technology has proven through the years to be the most cost effective way to meet high charging demands from any 12v sources. Packed in a durable container, this battery is sure to stand the test of time. These batteries have a higher than normal float voltage so with the vehicle on and the alternator charging these will give even more reserve.
Highlights
Technical Details
02 Tech specs
By the numbers
RMS Power 01
1,750W
Continuous rating
Capacity 02
55Ah
Rated
CCA 03
825A
Cranking amps
Weight 04
36.30lb
Per unit
- Voltage
- 12 Volts
- Nominal Voltage
- 12.8 V
- Maximum Discharge Current
- 1650 Amps
- Cranking Amps (CA)
- 825 Amps
- Cold Cranking Amps (CCA)
- 400 Amps
- Watts (RMS)
- 1750W
- Float Charging Voltage
- 13.5 to 13.8 Vdc / unit average at 25°C (77°F)
- Recommended Charging Current
- 16.5 Amps
- Bolt / Terminal Type
- Theard Lead Alloy Recessed / M6 Bolt
- Overall Height (Without Terminals)
- 8.26″ / 210mm
- Capacity
- 55Ah @ 10hr-rate to 1.8V per cell @ 25°C (77°F)
- Overall Length
- 9″ / 230mm
- Overall Width
- 5.43″ / 138mm
- Overall Height
- 8.46″ / 215mm
- Weight
- 36.30 Lbs / 16.5 kg
- Battery Type
- AGM
- Internal Resistance
- Approx. 6.5 mΩ
- Nominal Operating Temperature Range
- 25°C +/- 3° (77°F +/- 5°)
- Battery Group
- U1
