Description
Product Overview
The DS18 Hydro All Elements Series is comprised of many components and accessories to make any build imaginable come to life. With over 50 marine grade compliant products we have whatever you may need for your ATV, UTV, Side by Side, Jeep, Motorcycle, Boat, or anything in between. We invite you to get as creative as possible and make the loudest, clearest system on any terrain, water body, or air.
The DS18 Hydro Motorsport and Marine Series rugged yet sleek design, provide its users with trouble free, waterproof (IP65), amazing sound quality. Engineered for all elements, these speakers/subwoofers are a great addition to your marine life and motorsports! The Hyrdo Series range in size from 6.5″, 8″, and 10″ with MAX Power up to 600W! Also equipped with an integrated RGB LED Lighting, high temp injection molded composite, ASA Grills with UV coating or a high gloss basket with UV coating.
All speakers come with both clamps for easy installation.
Highlights
Technical Details
Download NXL-PS6 Product Manual
Model
NXL-PS6
Nominal Diameter
6.5″
Type
2-way
Nominal Impedance (Ohms)
4Ω
Frequency Response (Hz)
65Hz – 23KHz
Voice Coil Diameter
1.2″
Power Handling
100W RMS / 300W Max
Fs-Free Air Resonance (Hz)
65
Qts
0.622
Vas-cu.ft
0.3
Sensitivity
91dB
Xmax
0.16″
Mounting Height
7.77″
Mounting Depth
6.25″
Mounting Diameter
6.93″
Technical Data
| Specification | Details |
|---|---|
| Size | 6.5 inch |
| RMS Power | 100 Watts RMS |
| Peak Power | 300 Watts Max |
| Impedance | 4 Ohms |
| Sensitivity | 91dB |
| Frequency Response | 65 Hz – 23 kHz |
| Mounting Depth | 6.25″ |
| Model | NXL-PS6 |
| Nominal Diameter | 6.5″ |
| Type | 2-way |
| Nominal Impedance (Ohms) | 4Ω |
| Frequency Response (Hz) | 65Hz – 23KHz |
| Voice Coil Diameter | 1.2″ |
| Power Handling | 100W RMS / 300W Max |
| Fs-Free Air Resonance (Hz) | 65 |
| Qts | 0.622 |
| Vas-cu.ft | 0.3 |
| Xmax | 0.16″ |
| Mounting Height | 7.77″ |
| Mounting Diameter | 6.93″ |
