DS18 NXL-X1200.5D NXL 5-Channel Full-Range Class D IP67 Marine and Powersports Amplifier 4 x 150 @ 4-Ohm and 1 x 600 @ 2-Ohm Watts Rms

$724.95

Lease for as low as $32.76/week. Apply Now

Peak Power2,800W
Weight2.4kg
01 Overview

The details

Product Overview

The DS18 NXL Series was developed for people who want a very a small audio footprint that is capable of putting out lots of power and sound in a small and waterproof package.

The NXL Series of amps are one of our most efficient lines with great power output all while withstanding the elements. These amps come in 1 channel, 4 channel, and 5 channel to help you power a wide array of speaker setups.

Being full range amps, they also can be run on subwoofers, mid-ranges, and tweeters. The high pass and low pass filters will help you tune your speaker choice accurately so you can obtain crystal clarity from low volume levels all the way to maximum for the ultimate audio experience.

All our units have stable and reliable 4-layer PCB layouts, IP67 waterproof rating for power sports, has an ultra-compact size for easy installation, and has audio precision quality control verification.

The NXL Marine Amplifier series is exactly what the outdoors lover will need for their vehicle’s audio to brave the trails, enjoy the lake, or any situation that needs a strong versatile waterproof amplifier.

AMPLIFIERS ARE NOT FOR SUBMERSIBLE USE, WILL VOID WARRANTY

Highlights

Great For:

Technical Details NXL-X1200.5D Product Manual

02 Tech specs

By the numbers

NXL-X1200.5D · Manufacturer rated
Peak Power 01
2,800W
Short-burst rating
Weight 02
2.4kg
Per unit

Channels
5 Channel
Amplifier Class
Digital
Impedance
4 Ohms
Total Watts (Peak)
2800W
RMS Power @ 4 ohm
4 x 150W + 350W (SUB)
RMS Power @ 2 ohm
4 x 200W + 600W (SUB)
RMS Power @ 1 ohm
–
RMS Power @ 4 ohm Bridge
2 x 400W
Input Impedance
20KΩ
Channel Separation
60dB
Low Level Input Range
200mV-5V
X-Over Filter Range
40Hz-2KHz / 50Hz-250Hz (SUB)
Bass Boost Range
0-18dB (SUB)
Infrasonic Filter
10Hz-55Hz (SUB)
Number of Channels
5
Minimum Impedance
2 Ohms (Stereo) / 4 Ohm (Bridge) / 2 Ohm (SUB)
Power Input Size
4GA Tinned OFC
Fuse Size
2 x 50A (100A)
Short Circuit Output Protection
Yes
Voltage Input Protection
Yes (7-16V)

Frequency Response
10Hz-20KHz
Efficiency @ 4ohm
0.85
Total Harmonic Distortion (THD)
< 0.05%
Bass Boost Frequency
42Hz (SUB)

Body Color / Finish
Black Brushed Aluminum

Overall Length
12.67″ / 322mm
Overall Height
1.77″ / 45mm
Heatsink Length
11.87″ / 301.7mm
Gross Single Unit Weight
2.4kg

Signal to Noise Ratio 1W@4Ω
> 100dB
Selectable X-Over
Yes (HPF/Full/LPF) / LPF Fixed (SUB)
Phase Selector
No
Amplifier Type
Stereo Full Range + Subwoofer
Led Indicators
Power / Protection / Clip
Thermal Protection
Yes (75°C)
Over-Load Protection
Yes
Overall Wide
4.4″ / 112mm
