DS18 PRO-DRNSC1.5DK 1″ Neodymium Driver And Horn Kit 160 Watts 1.5″ Polyimide 8-Ohm Vc
$99.95
Out of stock
The details
Product Overview
The PRO-DRNSC1.5DK boasts unmatched power handling for the Pro Audio sound you love. This neodymium compression driver ensures unparalleled performance that delivers impressive sound with striking clarity and limitless depth. Equipped with a highly durable 1.5” voice coil, these drivers are guaranteed to perform at their maximum potential for the entirety of any jam session. This compression driver doesn’t draw an excessive amount of power from your amplifier & ensures long lasting performance from your equipment. This variation of the PRO-DRNSC includes a non-removable horn throat so that it is ready to be quickly installed.
Highlights
Great For
Technical Details PRO-DRNSC1.5DK Product Manual
By the numbers
- Impedance
- 8 Ohms
- Nominal Impedance
- 8 ohm
- AES Power handling
- 80 W
- Program Power Handling
- 160 W
- Peak Power handling
- 320 W
- Recommended Hi Pass Crossover
- 2KHz
- Frequency Response
- 1K-20KHz
- Sensitivity (1w/1m) With Horn
- 111 dB
- Voice Coil
- 1.5 inch
- Voice Coil Diameter
- 1.5″ / 38mm
- Voice Coil Former Material
- Kapton
- Winding Material
- Aluminum
- Diaphragm Material
- Polyimide
- Magnet Material
- Neodymium (N38H）
- Magnet Weight
- 2.4 oz
- Body Color / Finish
- Silver / Raw
- Body Material
- Aluminum
- Color/Finish
- Silver / Raw
- Size
- 1 inch
- Mounting Depth
- 2.22″ / 56.5mm
- Nominal Diameter
- 3.15″ / 80mm
- Throat Diameter
- 1″ / 25.4mm
- Overall Diameter
- 3.15″ / 80mm
- Overall Depth
- 2.42″ / 61.5mm
- Mounting Hole Diameter
- 2.75″ / 70mm
- Pair or Single
- Single
- Sound Coverage
- 60° (round)
- Bolt Pattern (Horn)
- 2.13″ / 54mm
