The details
Product Overview
Why we stock the DS18 PRO-FR69NEO
The DS18 PRO-FR69NEO is a 6×9″ neodymium full-range bullet speaker and one of the loudest 6x9s DS18 makes. It handles 250 watts RMS (500 max) at 4 ohms with 98 dB sensitivity, plays from 100Hz to 9kHz, and needs 2.87″ of mounting depth.
It’s ideal for pro audio rear decks and 6×9 pods. Set a high-pass around 120Hz and power it with a full-range amp like the FRP-1.2K4. Need a round 6.5″ instead? See the PRO-FR6NEO.
Versatility is paramount in large and small audio systems alike. Many DS18 fans have been wanting a more powerful 6×9 so they can get clear and loud sound from their 6x9s. We have obliged the overwhelming requests by releasing our PRO-FR69NEO. This Neodymium driven midrange speaker will be the loudest 6×9 we have while also handling the most power.
The great thing about NEO motor structures is that you get better performance, higher wattage handing, better efficiency, and much lighter in weight than a traditional speaker with a ferrite motor structure. This is a 4 ohms speaker that handles 250w RMS and 500 W Peak power with a dB sensitivity rating of 98dB. This neo also has a built in bullet resonator to help this screaming full range all the way from 100Hz to 9000Hz with extreme clarity and loudness.
Technical Details Download PRO-FR69NEO Product Manual
Key Features
- Neodymium motor structure that handles more power, lighter, and more efficient than ferrite motors.
- Silver bullet resonator that will bring the loudness and clarity of this speaker to the highest pinnacle.
- High RMS rating of 250w RMS and 500w MAX @4 Ohms so you can have a very high powered 6×9 to blow away the competition.
- High decibel rating so it does not take max power to get the fullest sound.
By the numbers
- RMS Power
- 250 Watts RMS
- Peak Power
- 500 Watts Max
- Impedance
- 4 Ohms
- Nominal Impedance
- 4 Ohms
- RMS Power Handling
- 250w
- MAX Power Handling
- 500w
- Recommended HI Pass Crossover
- 120Hz
- Sensitivity
- 98 dB
- Frequency Response
- 100Hz-9KHz
- Sensitivity (1w/1m)
- 98dB
- Voice Coil Diameter
- 38.6mm/1.5″
- Voice Coil Former Material
- Kapton
- Winding Material
- CCAW
- Cone Material
- Paper
- Bullet Material
- Aluminum
- Surround Material
- Cloth
- Basket Material
- Aluminum
- Magnet Material
- Neodymium
- Magnet Weight
- 2.8 Oz
- Motor Diameter
- 4.13″
- Mounting Depth
- 2.874″
- Nominal Diameter
- 6×9″
- Displacement Volume
- 0.0524L
- Overall Diameter
- 9.44×6.57″
- Overall Depth
- 3.31″
- Front Mount Baffle Cutout
- 8.74×5.97″
