DS18 PRO-HA102/BK PRO Bolt On 2″ 35° 4.84″ Depth Aluminum Horn

Description

DS18 PRO-HA102 Bolt On 2″ 35° 4.84″ Depth Aluminum Horn

All aluminum casing with brushed DS18 logo. This throat will require a 4 bolt pattern on your driver to attach correctly. Now you can save some space while having crazy loud directional sound from your drivers.

Highlights

• Aluminum frame with brushed DS18 logo
• 4 bolt pattern for compatibility for most bolt on drivers
• Installation Type: Bolt-on
• Throat Diameter: 2″ / 50.8mm
• Nominal Horn Diameter: 6.5″
• Sound Coverage: 35° Rounded

Technical Details
Download PRO-HA102 Product Manual

Measurements

• Overall Diameter: 7.08″ / 180mm
• Overall Depth: 5.18’’ / 131.50mm
• Driver Bolt Pattern: 4.05″/ 102mm x 4-0.26″ / 6.8mm
• Mounting Bolt Pattern: 6.33″ / 161mm x 4- 0.21″ / 5.5mm

Specifications

• 2”
• Bolt-On Throat 35°
• 4.84” Depth
• Black
• Aluminum
