DS18 PRO-TWX4 4.5″ Super Bullet Tweeter 280 Watts 1.75″ Titanium 4-Ohm Vc
$64.95
The details
Product Overview
Engineered and Designed in the US, the DS18 PRO Tweeters are the top of the line in the Pro Audio/Voceteo market. These bad boys deliver so much power that you’d think with one tweeter your whole sound system is ready to deploy for a major concert. Simply put, there are no tweeters that can compare to the sophistication, beauty, and precision of these tweeters especially in the Pro Audio/Voceteo World.
Thanks to the demands of our customers, after months of relentless tests and experiments, our team of audio-experts perfected the PRO TWX line. We are ecstatic to share with you the product of hard-work and “non-stop innovating attitude.” We are sure that you will love your new PRO Tweeters as much as we do.
Highlights
Technical Details PRO-TWX4 Product Manual
By the numbers
- Impedance
- 4 Ohms
- Nominal Impedance
- 4 Ohms
- AES Power Handling
- 140W
- Program Power Handling
- 280W
- Peak Power Handling
- 560W
- Recommended Hi Pass Crossover
- 2KHz
- Frequency Response
- 1.5KHz-20KHz
- Sensitivity (1w/1m)
- 108 dB
- Voice Coil Diameter
- 1.75” / 44.4mm
- Voice Coil Former Material
- Kapton
- Winding Material
- CCAW
- Diaphragm Material
- Titanium
- Magnet Material
- Ferrite
- Magnet Weight
- 16 oz
- Body Material
- Aluminum
- Bullet Material
- Aluminum
- Motor Diameter
- 3.56” / 90mm
- Size
- 4.5 inch
- Mounting Depth
- 2.76” / 70mm
- Nominal Diameter
- 4.53” / 115mm
- Overall Diameter
- 4.53” / 115mm
- Overall Depth
- 3.01“ / 76.5mm
- Front Mount Baffle Cutout
- 3.62” / 92mm
- Pair or Single
- Single
