DS18 PRO-X12MBASS PRO-X 12″ Mid-Bass Loudspeaker | 500W RMS 8-Ohm

$134.95

RMS Power500W
Peak Power1,000W
Sensitivity96dB
SKU: PRO-X12MBASS Categories: , , , Brand:
01 Overview

The details

Product Overview

Why we stock the DS18 PRO-X12MBASS

The DS18 PRO-X12MBASS is a 12″ PRO-X mid-bass at 8 ohms. It handles 500 watts RMS (1,000 max) with 96 dB sensitivity, uses a 2.5″ voice coil, and reaches down to 40Hz.

It needs 4.88″ of mounting depth and puts out thumping mid-bass on demand. Want a lighter 4 ohm neodymium version? See the PRO-X12MBASSNEO. Smaller space? Use the PRO-X10MBASS.

If you are needing a pro audio speaker that absolutely slays the mid-bass range then the look no further than the PRO-X12MBASS mid-bass speaker. This massive 12 not only looks amazing but powers out thumping mid-bass notes at demand. This mid-bass speaker is an amazing addition to any pro audio system that needs the mid notes played with authority.

Technical Details PRO-X12MBASS Product Manual

Key Features
  • Massive 12 inch design will bring out maximum punchy mid-bass.
  • Large 2.5″ voice coil that handles 500w RMS and 1000w peak power for sharp mid-bass.
  • A 40hz-5khz frequency range gives multiple tuning options for this huge mid-bass speaker to fit your systems needs.
  • With a 96db sensitivity rating, you don’t need huge amounts of power to get this mid-bass speaker to its optimum potential.

02 Tech specs

By the numbers

PRO-X12MBASS · Manufacturer rated
RMS Power 01
500W
Continuous rating
Peak Power 02
1,000W
Short-burst rating
Sensitivity 03
96dB
Efficiency
Size 04
12in
Nominal

RMS Power
500 Watts RMS
Peak Power
1000 Watts Max
Impedance
8 Ohms
Nominal Impedance
8 ohms
RMS Power Handling
500W
MAX Power Handling
1000W
Recommended Hi Pass Crossover
60 Hz

Sensitivity
96 dB
Frequency Response
40Hz-5KHz
Sensitivity (1w/1m)
96dB

Voice Coil
2.5 inch
Voice Coil Diameter
2.5
Voice Coil Former Material
KSV
Winding Material
SV
Cone Material
Paper
Dustcap Material
Paper
Surround Material
Cloth
Basket Material
Steel
Basket Color/Finish
Glossy Red
Magnet Material
Ferrite
Magnet Weight
65oz
Motor Diameter
6.69″

Size
12 inch
Mounting Depth
4.88
Nominal Diameter
12″
Displacement Volume
0.55L
Overall Diameter
12.12
Overall Depth
5.19
Front Mount Baffle Cutout
10.9

Pair or Single
Single
Grill Included
No
