DS18

DS18 PSW12.2D PS Shallow-Mount Water Resistant 12″ Subwoofer | 600W RMS DVC 2-Ohm

$199.95

RMS Power600W
Peak Power1,200W
Sensitivity85dB

Out of stock

01 Overview

The details

Product Overview

Why we stock the DS18 PSW12.2D

The DS18 PSW12.2D is a shallow-mount, water-resistant 12″ subwoofer with a 3″ dual 2 ohm voice coil. It handles 600 watts RMS (1,200 max) with 85 dB sensitivity and plays from 20Hz to 600Hz.

It needs only 3.3″ of mounting depth. Need dual 4 ohm? Use the PSW12.4D. Smaller box? See the PSW10.2D.

There’s always space for bass with the PSW12.2D!

The PSW12.2Dmounts in depths as small as 3.9” and can be utilized in both ported and sealed boxes for great bass in a tight area. The high-quality push terminals on the PSW series subwoofers also make connection to your speaker wire and amp extremely easy.

This sub handles 600 W RMS and 1200 W MAX Power with a 85 dB sensitivity: high sensitivity for a shallow mount sub allowing this light subwoofer to reproduce heavy clear bass!

The PPI Molding on the cone used by the PSW12.2Dis also water resistant, making this speaker perfect for your bike, off-road or marine vehicle. The steel basket gives this speaker even stronger resistance against shock and vibration.

This sub comes in 2 Ohms Dual Voice Coil configuration so if wired appropriately it’s insane power will bring all your music to life!

Highlights

Great For

Technical Details Download PSW12.2D Product Manual

02 Tech specs

By the numbers

PSW12.2D · Manufacturer rated
RMS Power 01
600W
Continuous rating
Peak Power 02
1,200W
Short-burst rating
Sensitivity 03
85dB
Efficiency
Size 04
12in
Nominal

RMS Power
600 Watts RMS
Peak Power
1200 Watts Max
Impedance
2 Ohms
Nominal Impedance
2+2 Ohms
RMS Power Handling
600 W
MAX Power Handling
1200 W
Recommended Lo Pass Crossover
80 Hz

Sensitivity
85 dB
Frequency Response
20 – 600 Hz
Sensitivity (1w/1m)
85 dB
Sealed Box Output Response
40 Hz

Voice Coil Diameter
3″ / 76.2 mm
Voice Coil Former Material
Aluminum
Winding Material
Copper
Cone Material
Water Resistant PPI
Surround Material
Rubber
Basket Material
Steel
Basket Color/Finish
Matt Black
Magnet Material
Ferrite
Magnet Weight
68 Oz
Motor Diameter
8″ / 203 mm

Size
12 inch
Mounting Depth
3.3″ / 84 mm
Nominal Diameter
12” / 304.8 mm
Displacement Volume
0.95L / 0.033ft3
Sealed Internal Volume
28L / 1ft3
Overall Diameter
12.2″ / 310 mm
Overall Depth
3.9″ / 100 mm
Front Mount Baffle Cutout
10.6″ / 270 mm
