DS18 RV.R1 RV and Trailers Headunit 2.75″ LCD screen , 2 Zones, 4 volts Output,HDMI, BT, RDS 4 X 50 Watts

$174.95

Lease for as low as $7.91/week. Apply Now

RMS Power17W
Peak Power50W
Weight14.2oz
01 Overview

The details

Product Overview

Take control of your RV’s Audio with DS18’s RV.R1!

The RV.R1 was made to give recreational vehicle users a high-quality receiver with the features to expand the sound available to them while they take on the open road.

This easy mount stereo receiver comes equipped with all the features needed to take your recreational vehicle’s audio to the next level: FM Radio, AM Radio, Bluetooth, USB connectivity, and HDMI pass through.

RDS integrated in the FM Radio tells users exactly what song they’re listening to, and stores up to 18 memory stations. The Bluetooth (v5.0) installed in this receiver works at extreme distances so you can stream your music from anywhere. The USB Port is made for music streaming and charging any device. Users also have the choice of connecting their television to their receiver to play its contents from anywhere in the vehicle.

A 2-Band equalizer has been incorporated in this receivers features for complete control over two parts of your frequency spectrum. Take even more control over the audio in your vehicle with Volume/Bass/Treble/Balance/EQ/Loudness features in this receivers Audio Control Equalizer.

At 4 ohms this unit offers 4CH x 17W Continuous Power Output and 50W x 4CH Max Power Output which is generally enough to power all entry level speakers. The PRE-AMP outputs will deliver a maximum of 4 volts for subwoofers, and 2.5 volts per zone for your amplifiers to get the clearest and distortion free sound available. Also 3 sets of preamp outputs (SUB, Front, and Rear) will be there for you to configure to your specific setup.

Highlights

Great For

Technical Details Download RV.R1 Product Manual

02 Tech specs

By the numbers

RV.R1 · Manufacturer rated
RMS Power 01
17W
Continuous rating
Peak Power 02
50W
Short-burst rating
Weight 03
14.2oz
Per unit

Rated Power Source
14.4V DC (11V to 16V operation)
Maximum Current Consumption
10 Amp
Maximum Power Output
50W X 4 Ch @ 4 ohms (14.4v)
Continuous Power Output
17W x 4 Ch @ 4 ohms (14.4v)
Pre-output Level
Zone 1/2: 2.5 Volts / Subwoofer: 4 Volts (14.4V)
Type / Class
V1.1 / V2.0 / MSC / MTP / FAT16 / FAT32 / NTFS
Max Current Supply
1.5 Amp (Charging USB port)
Aux Input
Front 3.5mm Jack Stereo Audio / Rear RCA A/V

Frequency Response
20Hz – 20Khz

Bezel frame
130mm x 112mm x 17mm

Weight
14.2Oz / 403 grams
Screen Size
2.75 inch / 66 x 31mm
Format Files Supported
MP3, WMA, FLAC, MAV
Memory Size Reader
up to 64 Gb
Number of USB Ports
1 x Front (Audio / Charging)

Chassis
97mm x 100mm x 150mm
Display Type
VA LCD
Temperature Operation
-20°C to +60°C (14°F to 140°F)
Equalizer
2 bands (Bass: 100Hz, Treble: 10KHz) Gain: +/- 7dB
Preset EQ
Flat / Rock / Pop / Classic
Audio Control
Volume / Balance / Loudness / Bass / Treble / Zone Volume
Signal to Noise Ratio
>60dB
Info Display Format
ID3 Tag
BT Version / Services
V5.0 / Audio Streaming
Audio Protocol
A2DP
Headphone
Front 3.5mm Jack Stereo
HDMI
Rear Output (To HDTV) / Front Input (From Source)
