Why we stock the DS18 SB12A
The DS18 SB12A is a loaded, amplified shallow enclosure with a 12″ sub and a built-in digital amp rated 350 watts RMS. The sealed 0.56 cubic foot MDF box plays from 30Hz to 250Hz with 87 dB sensitivity.
It gives deeper bass than the SB10A in a box that’s still shallow. Already have an amp? Use the passive SB12.
Subwoofers are a must have for any audio system. Some audio enthusiasts don’t have a lot of room for big subs, for example, in single cab trucks. Now we have a option for people craving great bass but don’t have much space for it.
The SB12A is a slim 12 inch subwoofer in a sealed box that is powered by a powerful, built in 350w RMS amplifier that is sure to get the bass thumping hard in the minimal space that you have available available in your vehicle.
Highlights
Technical Details SBA-12A Product Manual
By the numbers
- Amplifier Class
- Digital
- RMS Power
- 350 Watts RMS
- Speaker Size
- 12″ / 312mm
- Total Impedance
- 2 ohms
- RMS Power Handling
- 350W
- MAX Power Handling
- 700W
- Number of Channels
- 1 CH
- Minimum Impedance
- 2 Ohms
- Low Level Input Range
- 0.1-0.6 V
- High Level Input Range
- Yes
- X-Over Filter Range
- 51 – 200 Hz
- Bass Boost Range
- 0-6 dB
- Power Input Terminal Size
- 8 GA
- Fuse Size
- 30 A
- DC Output Protection
- Yes
- Short Circuit Output Protection
- Yes
- Voltage Input Protection
- Yes (16v)
- Frequency Response
- 30-250Hz
- Sensitivity (1w/1m)
- 87dB
- Efficiency @ 4 ohms
- 75%
- Bass Boost Frequency
- 50Hz
- Box Material
- 0.59″ MDF
- Finish Material
- Non-Woven fabric
- Voice Coil Diameter
- 1.75″ / 44.43mm
- Voice Coil Former Material
- Aluminum
- Winding Material
- EISV
- Cone Material
- IPP
- Surround Material
- Rubber
- Basket Material
- SPCC
- Magnet Material
- Ferrite
- Magnet Weight
- 50 Oz
- Size
- 12 inch
- Internal Volume
- 16L / 0.56ft3
- Box Type
- Sealed Box
- Height
- 14.96″ / 380mm
- Width
- 19.3″ / 490mm
- Depth 1
- 4.92″ / 125mm
- Depth 2
- 7.4″ / 188mm
- Load Configuration
- Parallel In
- (-3dB) Dropping Point
- 45Hz
- Amplifier Type
- Monoblock Subwoofer
- Signal to Noise Ratio
- 75 dB
- Total Harmonic Distortion (T.H.D)
- 0.30%
- Selectable X-Over
- LPF Fixed
- Phase Selector
- 0-180°
- Led Indicator
- Power – Protection
- Remote Level Control
- Yes
- Thermal Protection
- Yes (75°C / 167°F)
- Over-Load Protection
- Yes
