DS18 SRW12.4D SRW Shallow-Mount 12″ Subwoofer 220 Watts Rms DVC 4-Ohm

$125.95

We have further developed our shallow mount sub to include the much requested SRW12.4D 12-inch option.

  • Size: 12"
  • RMS Power: 220W
  • MAX Power: 440W
  • Impedance: 4 + 4 Ohms
  • Frequency Response: 25Hz – 250Hz
  • Mounting Depth: 3.54" (90mm)
RMS Power220W
Peak Power440W
Size12in

Out of stock

01 Overview

The details

Product Overview

Why we stock the DS18 SRW12.4D

The DS18 SRW12.4D is a shallow-mount 12″ subwoofer with a 2″ dual 4 ohm voice coil. It handles 220 watts RMS (440 max) and plays from 25Hz to 250Hz.

It needs only 3.54″ of mounting depth. Need a single coil? Use the SRW12.4. Smaller box? See the SRW10.4D.

We have further developed our shallow mount sub to include the much requested SRW12.4D 12-inch option. This sub has all the features that our shallow mount 10" but with more cone area in 12". These shallow subs take 220w RMS and 440w Peak so you can get that extra thump you need with the added cone area of the 12. The sensitivity is high for a sub coming in at 88dB so it will not take full power to reach maximum potential which gives you an array of amplifier options. They will come in DVC and SVC so you can wire to your amps recommended impedance with ease. These subs are perfect for the enthusiast that is wanting to keep storage space by using shallow mounted subs so the box depth can be much shallower than normal for much more bass!

Manual

02 Tech specs

By the numbers

SRW12.4D · Manufacturer rated
RMS Power 01
220W
Continuous rating
Peak Power 02
440W
Short-burst rating
Size 03
12in
Nominal
Weight 04
45oz
Per unit

RMS Power
220W
MAX Power
440W
Impedance
4 + 4 Ohms

Frequency Response
25Hz – 250Hz

Voice coil size
2"
Magnet
Ferrite
Magnet Weight
45 oz
Basket
Steel
Cone
Paper
Surround
Rubber Edge
Voice Coil Former Material
Aluminum

Size
12"
Mounting Cut-Out
10.98" (279mm)
Mounting Depth
3.54" (90mm)
Overall Diameter
12.44" (316mm)
Optimum Ported FT3
1.5 FT3

Model
SRW12.4D
Type
Shallow Subwoofer
Optimum Sealed FT3
0.75FT3
