DS18 SXE-1200.4/BK SXE Class A/B 4-Channel Full-Range Amplifier 4 x 60 RMS @ 4-Ohm 1200 Watts

$154.95

Lease for as low as $7/week. Apply Now

RMS Power400W
Peak Power1,200W
Weight1.76kg
SKU: SXE-1200.4/BK Categories: , , , Brand:
01 Overview

The details

.woocommerce-tabs ul.wc-tabs{display:none}.woocommerce-Tabs-panel–description>h2:first-child{display:none}.woocommerce-Tabs-panel–description>p:empty{display:none}.dv8-brand{color:#e4321f}.dv8-spec{–r:#e4321f;–rd:#a3160b;–ink:#111114;–ink2:#4a4544;–line:#e5e0df;–wash:#faf8f8;background:#fff;color:var(–ink);line-height:1.62;max-width:100%}.dv8-spec *{box-sizing:border-box}.dv8-spec__mono{font-family:ui-monospace,SFMono-Regular,’SF Mono’,Menlo,Consolas,monospace;font-variant-numeric:tabular-nums;letter-spacing:-.01em}.dv8-spec__sec{border-top:1px solid var(–line)}.dv8-spec__sec:last-of-type{border-bottom:1px solid var(–line)}.dv8-spec__sum{display:flex;align-items:center;gap:14px;cursor:pointer;list-style:none;user-select:none;padding:16px 2px}.dv8-spec__sum::-webkit-details-marker{display:none}.dv8-spec__sum::marker{content:”}.dv8-spec__sum:focus-visible{outline:2px solid var(–r);outline-offset:3px}.dv8-spec__sum:hover .dv8-spec__t{color:var(–rd)}.dv8-spec__t{font-size:12px;font-weight:800;letter-spacing:.15em;text-transform:uppercase;color:var(–r);transition:color .15s}.dv8-spec__lead{flex:1 1 auto;min-width:18px;border-bottom:1px dotted #bdb6b5;transform:translateY(-2px)}.dv8-spec__sign{flex:none;width:22px;height:22px;display:grid;place-items:center;font-size:17px;line-height:1;color:var(–r);transition:transform .2s ease}.dv8-spec__sign::after{content:’+’}.dv8-spec__sec[open] .dv8-spec__sign{transform:rotate(135deg)}.dv8-spec__body{padding:2px 2px 22px}.dv8-spec__lede{margin:0 0 13px;font-size:15.5px;color:var(–ink2);max-width:68ch}.dv8-spec__lede:last-child{margin-bottom:0}.dv8-spec__lede b,.dv8-spec__lede strong{color:var(–ink);font-weight:700}.dv8-spec__lede a{color:var(–r);text-decoration:underline;text-underline-offset:2px}.dv8-spec__feats{list-style:none;margin:0;padding:0;display:grid;gap:1px;background:var(–line);border:1px solid var(–line)}.dv8-spec__feat{background:#fff;padding:14px 18px;transition:background .18s,box-shadow .18s}.dv8-spec__feat:hover{background:var(–wash);box-shadow:inset 3px 0 0 var(–r)}.dv8-spec__feat b{display:block;font-size:13px;font-weight:750;margin-bottom:3px}.dv8-spec__feat span{font-size:14px;color:var(–ink2)}.dv8-spec__tw{overflow-x:auto;-webkit-overflow-scrolling:touch}.dv8-spec__table{width:100%;border-collapse:collapse;font-size:14px;min-width:380px}.dv8-spec__table thead th{background:linear-gradient(180deg,var(–r),var(–rd));color:#fff;text-align:left;padding:11px 18px;font-size:10.5px;font-weight:800;letter-spacing:.14em;text-transform:uppercase;white-space:nowrap;border:none}.dv8-spec__table tbody tr{border-bottom:1px solid var(–line);transition:background .16s,color .16s,transform .16s,box-shadow .16s}.dv8-spec__table tbody tr:nth-child(even){background:var(–wash)}.dv8-spec__table tbody tr:hover{background:linear-gradient(90deg,var(–r),var(–rd));color:#fff;transform:scale(1.012);box-shadow:0 4px 14px rgba(228,50,31,.32);position:relative;z-index:1}.dv8-spec__table tbody tr:hover td{color:#fff}.dv8-spec__table td{padding:10px 18px;vertical-align:top;border:none}.dv8-spec__k{font-weight:650;width:46%}.dv8-spec__v{font-size:13px;color:var(–ink2)}.dv8-spec__sls{list-style:none;margin:12px 0 0;padding:0;display:grid;gap:1px;background:var(–line);border:1px solid var(–line)}.dv8-spec__sl{background:#fff;padding:11px 18px;font-size:13.5px;transition:background .18s,box-shadow .18s}.dv8-spec__sl:hover{background:var(–wash);box-shadow:inset 3px 0 0 var(–r)}.dv8-spec__fits{list-style:none;margin:0;padding:0;display:grid;gap:10px}.dv8-spec__fit{border:1px solid var(–line);border-left:3px solid var(–r);padding:13px 17px;transition:background .18s}.dv8-spec__fit:hover{background:var(–wash)}.dv8-spec__fit b{display:block;font-size:13px;font-weight:750;margin-bottom:3px}.dv8-spec__fit span{font-size:14px;color:var(–ink2)}.dv8-spec__tip{margin:22px 0 0;background:#111114;color:#f0eeed;padding:18px 22px;border-left:4px solid var(–r)}.dv8-spec__tip b{display:block;font-size:10.5px;font-weight:800;letter-spacing:.15em;text-transform:uppercase;color:#ff6a53;margin-bottom:6px}.dv8-spec__tip span{font-size:14.5px}@media (max-width:560px){.dv8-spec__table tbody tr:hover{transform:none}.dv8-spec__table td{padding:9px 13px}}@media (prefers-reduced-motion:reduce){.dv8-spec *{transition:none!important}.dv8-spec__table tbody tr:hover{transform:none}}

Product Overview

DS18’s SXE series of amps was designed for users looking for an extreme increase to the quality of music reproduced by their vehicle. The SXE-1200.4 guarantees your sound system’s speakers perform at their peaks on every use.

The SXE series of amplifier gives users the ability to tailor the audio reproduced by their vehicle to their personal listening preferences through the use of it’s fully variable crossover, adjustable gain input sensitivity, and multi-channel amplifier design: everything you need to take control of your listening experience.

As a Class A/B amplifier, the SXE series uses power transformers significantly smaller than your average amplifier, making it the perfect size for any vehicle’s custom build: but, what it lacks in size it makes up for in power. The SXE-1200.4 has a power output of 200W x 2 CH bridged at 4-ohms, 100W x 4 CH at 2-ohms, 60W x 4 CH at 4-ohms: perfect power settings to supercharge any custom build.

Highlights

Great For

Technical Details SXE-1200.4 Product Manual

02 Tech specs

By the numbers

SXE-1200.4/BK · Manufacturer rated
RMS Power 01
400W
Continuous rating
Peak Power 02
1,200W
Short-burst rating
Weight 03
1.76kg
Per unit

Channels
4 Channel
Amplifier Class
Analog (AB)
Impedance
4 Ohms
Total Watts (Peak)
1200W
RMS Power
400W (4 x 100W @ 2 ohm)
RMS Power @ 4 ohms
4 x 60W
RMS Power @ 2 ohms
4 x 100W
RMS Power @ 1 ohm
/
RMS Power @ 4 ohms Bridge
2 x 200W
Damping Factor
170
Input Impedance
20kΩ
Channel Separation
45dB
Low Level Input Range
200mV-5V
High Level Input
/
X-Over Filter Range
40Hz-2KHz
Bass Boost Range
/
Infrasonic Filter
/
Number of Channels
4
Minimum Impedance
2 Ohms Stereo / 4 Ohms Bridge
Power Input Terminal Size
4Ga
Fuse Size
2 x 25A (50A)
DC Output Protection
Yes
Short Circuit Output Protection
Yes
Voltage Input Protection
Yes (16.5v)

Frequency Response
10Hz-20KHz
Efficiency @ 4 ohms
64%
Total Harmonic Distortion (THD)
0.05%
Bass Boost Frequency
/

Body Color / Finish
Red / Black Brushed Aluminum

Overall Length
9.8″ / 249.3mm
Overall Height
1.8″ / 48mm
Heatsink Length
8.34″ / 212mm
Gross Single Unit Weight
1.76KG

Signal to Noise Ratio
90dB
Selectable X-Over
HPF/FULL/LPF
Phase Selector
/
Amplifier Type
Stereo Full Range
Led Indicator
Power/Protect/Clip
Remote Level Control
/
Cooling Fan
Yes
Voltmeter
/
Thermal Protection
Yes (80℃)
Over-Load Protection
Yes
Clipping Protection
Yes
Overall Wide
5.5″ / 140mm
