The details
Product Overview
DS18’s SXE Amplifier Series was designed for users looking to increase the quality of music reproduced by their vehicle.
The SXE series of amplifier gives users the ability to tailor the audio reproduced by their vehicle to their personal listening preferences through the use of it’s fully variable crossover, adjustable gain input sensitivity, bass knob, and multi-channel amplifier design.
As a Class D amplifier, the SXE series uses power transformers significantly smaller than your average amplifier, making it the perfect size for any vehicle’s custom build: but, what it lacks in size it makes up for in power.
The SXE-2500.1D has a power output of 800W at 1-ohm, 600W at 2-ohms, 300W at 4-ohms: perfect power settings to supercharge any custom build.
Highlights
Great For
Technical Details Download SXE-2500.1 Product Manual
By the numbers
- Channels
- 1 Channel
- Amplifier Class
- Digital (D)
- RMS Power
- 800 Watts RMS
- Impedance
- 1 Ohms
- Total Watts (Peak)
- 2500W
- RMS Power @ 4 ohms
- 300W
- RMS Power @ 2 ohms
- 600W
- RMS Power @ 1 ohm
- 800W
- RMS Power @ 4 ohms Bridge
- N/A
- Damping Factor
- 140
- Input Impedance
- 20kΩ
- Channel Separation
- N/A
- Low Level Input Range
- 200mV-5V
- High Level Input
- No
- X-Over Filter Range
- 50-250Hz
- Bass Boost Range
- 0-18dB
- Infrasonic Filter
- 10-55Hz
- Number of Channels
- 1
- Minimum Impedance
- 1 Ohm
- Power Input Terminal Size
- 4Ga
- Fuse Size
- 2 x 40A (80A)
- DC Output Protection
- Yes
- Short Circuit Output Protection
- Yes
- Voltage Input Protection
- Yes (16.5v)
- Frequency Response
- 10Hz-250Hz
- Efficiency @ 4 ohms
- 0.8
- Total Harmonic Distortion (THD)
- 0,05%
- Bass Boost Frequency
- 45Hz
- Body Color / Finish
- Red / Black Brushed Aluminum
- Overall Length
- 8″ / 205mm
- Overall Height
- 1.8″ / 48mm
- Heatsink Length
- 6.6″ / 168mm
- Gross Single Unit Weight
- 1.5KG
- Signal to Noise Ratio
- 90dB
- Selectable X-Over
- Fixed LPF
- Phase Selector
- 0-180°
- Amplifier Type
- Monoblock Subwoofer
- Led Indicator
- Power/Protect/Clip
- Remote Level Control
- Yes
- Cooling Fan
- No
- Voltmeter
- No
- Thermal Protection
- Yes 80°C
- Over-Load Protection
- Yes
- Clipping Protection
- Yes
- Overall Wide
- 5.5″ / 140mm
