DS18 ZXI-44 ZXI 4″ 2-Way Coaxial Speakers with Kevlar Cone | 50 Watts RMS 4-Ohm
$79.95
The details
Product Overview
Why we stock the DS18 ZXI-44
The DS18 ZXI-44 is a pair of 4″ 2-way coaxials with Kevlar cones. They handle 50 watts RMS (150 max) at 4 ohms with 88 dB sensitivity and play from 80Hz to 20kHz.
They’re a quick upgrade for dash and small door openings. Need a 3.5″ instead? See the ZXI-3542. Want more power handling in a 4″? Look at the EXL-SQ4.0.
The ZXI series is the go to DS18 line for great sounding audio that not only has very high volume, but also amazing sound quality for an amazing price. The ZXI-44 is a 4″, 4 ohms coaxial speaker designed for mid tier audio enthusiasts to the extreme as they have an amazing range of frequencies and loudness. The 2 – way design will ensure that you receive a full range of frequencies for an audio experience that you will truly remember.
Highlights
Technical Details Download ZXI-44 Product Manual
By the numbers
- RMS Power
- 50 Watts RMS
- Impedance
- 4 Ohms
- Nominal Impedance
- 4 ohm
- RMS Power Handling
- 50 Watts
- MAX Power Handling
- 150 Watts
- Recommended HI Pass Crossover
- 100Hz
- Speaker Type
- 2-Way
- Frequency Response
- 80Hz-20Khz
- Sensitivity (1w/1m)
- 88dB
- Excursion (one way)
- 2.3mm
- Free Air Resonance
- 95Hz
- BL Factor
- 4.583
- Voice Coil Diameter
- 0.8″ / ø20.4mm
- Voice Coil Former Material
- KSV
- Winding Material
- EISVM
- Cone Material
- Glass fiber
- Surround Material
- Rubber
- Basket Material
- Steel
- Magnet Material
- Barium Ferrite
- Magnet Weight
- 0.3 oz / 8.5g
- Diaphragm Material
- PEI
- Cone Area
- 55.4cm2
- Motor Diameter
- 3.31” / 84mm
- Size
- 4 inch
- Nominal Diameter
- 1″ / 25.4mm
- Equivalent Volume
- 1.59L
- Overall Diameter
- 3.94“ / 100mm
- Overall Depth
- 2.70” / 71mm
- Front Mount Baffle Cutout
- 3.66” / 93mm
- Mouting Depth
- 2.20” / 56mm
- Mechanical Factor
- 9
- Electrical Factor
- 0.8
- Total Factor
- 0.74
- Mechanical Mass
- 8.47g
- Mechanical Compliance
- 364.9mm/N
- DC Resistance
- 3.5 ohm
- Mechanical Mass w/o air
- 8.0g
