Description
Product Overview
The Alpha v2 Series of subwoofers is our all around daily entry level sub. A single wide high strength magnet and a standard high compression pole cap are the foundation for this motor. A multilayer foam surround is attached to a fiber impregnated linear kraft pulp cone which helps keep things under control in high power applications. A 3″ 4 layer aluminum voice coil yields 17mm of Xmax while keeping the motor force high. The Alpha v2series will work in most enclosure types (sealed, ported, bandpass). Light weight and versatile, the Alpha v2 Series works in a variety of applications from incredibly detailed sound quality systems, to ground pounding multi sub monsters. Gloss carbon fiber caps are standard and you have the option for a third spider for increased mechanical power handling for some applications.
Features
Single 1, 2, or 4 Ohm Cast basket Wrap around gasket Linear reinforced cone Mulit-layer wide foam surround Push terminal Extra heavy lead wire FEA optimized motor 3” diameter 4 layer coil Single wide high grade magnet Dual progressive spiders 6″ Gloss Carbon dustcap Compression cooling 1000wrms
THIELE-SMALL PARAMETERS
Technical Data
| Specification | Details |
|---|---|
| Size | 12 inch |
| RMS Power | 1000 Watts RMS |
| Impedance | 4 Ohms |
| Coils | S1/S2/S4 |
| FS | 56.1 |
| RE | .8/1.6/3.3 |
| QMS | 8.04 |
| QES | 0.41 |
| QTS | 0.39 |
| MMS | 190g |
| VAS | 5.75 l |
| BL (NA) | 15.9 |
| XMAX | 17mm (One Way) |
| RMS | 1000W |
