SoundQubed C Series C4-1500 4 Channel Class D Amplifier 1500W SQ-C4-1500
$549.95
The C4-1500 is the 4-channel for builds where the front stage really has to compete.
- RMS Power @ 4 ohm: 4 x 200W
- RMS Power @ 2 ohm: 4 x 375W
- RMS Power @ 4 ohm Bridged: 2 x 700W
- Frequency Response: 10Hz-30KHz
- Minimum Impedance: 2 Ohm Stereo / 4 Ohm Bridge
Out of stock
The details
Product Overview
SoundQubed C Series C4-1500 4 Channel Class D Amplifier 1500W – The C4-1500 is the 4-channel for builds where the front stage really has to compete. It makes 4 x 375 watts RMS at 2 ohms, or 2 x 700 bridged, with a 10 Hz to 30 kHz frequency response. DV8 Shop is an authorized SoundQubed dealer.
Pair it with pro-audio midranges and compression tweeters and it’ll keep up with a serious sub setup. Each channel pair has its own selectable crossover, channels 3 and 4 add band-pass with an X1/X10 multiplier, and the chassis is just over 8 inches long.
Every C Series amp is checked on Audio Precision test gear before it leaves SoundQubed, and each one carries thermal, overload, DC output, short-circuit and voltage protection.
By the numbers
- RMS Power @ 4 ohm
- 4 x 200W
- RMS Power @ 2 ohm
- 4 x 375W
- RMS Power @ 4 ohm Bridged
- 2 x 700W
- Damping Factor
- 92
- Channel Separation
- 40dB
- Input Impedance
- 22K ohms
- Low Level Input Range
- 350mV-7V
- X-Over Filter Range (CH 3/4)
- HPF: 20Hz-2kHz / LPF: 100Hz-20kHz (X1/X10)
- Amplifier Class
- Digital
- Number of Channels
- 4
- Minimum Impedance
- 2 Ohm Stereo / 4 Ohm Bridge
- Power Input Terminal Size
- 4GA
- Recommended Fuse
- 110A
- DC Output Protection
- Yes
- Short Circuit Output Protection
- Yes
- Voltage Input Protection
- Yes
- Tiffany-Style RCA Inputs
- Yes
- Frequency Response
- 10Hz-30KHz
- Efficiency @ 4 ohm
- 85%
- Total Harmonic Distortion (THD)
- 0.10%
- X-Over Frequency Multiplier
- Yes
- Body Color
- Black
- Overall Length
- 8.19" / 208mm
- Overall Width
- 5.91" / 150mm
- Overall Height
- 2.17" / 55mm
- Heatsink Length
- 7.01" / 178mm
- Weight
- 5 lbs
- Dimensions
- 11 × 8 × 4 in
- Brand
- SoundQubed
- Series
- C Series
- Model
- C4-1500
- Signal to Noise Ratio
- 94dB
- Selectable X-Over (CH 1/2)
- HPF / FULL
- Selectable X-Over (CH 3/4)
- HPF / FULL / BPF
- Amplifier Type
- Stereo Full-Range
- LED Indicator
- Power / Protect / Clip
- Thermal Protection
- Yes
- Over-Load Protection
- Yes
