SoundQubed HDC Series 8 inch Midbass Speaker 400W RMS 4 Ohm SQ-HDCMB084
$389.95
The HDC 8-inch midbass speaker is rated at 400 watts RMS at 4 ohms.
- RMS Power: 400W
- Impedance: 4 Ohm
- Frequency Response: 69Hz – 6,000Hz
- Sensitivity (1W/1m): 92 dB
RMS Power400W
Peak Power800W
Xmax8.6mm
Out of stock
01 Overview
The details
Product Overview
SoundQubed HDC Series 8 inch Midbass Speaker 400W RMS 4 Ohm – The HDC 8-inch midbass speaker is rated at 400 watts RMS at 4 ohms. It fills the gap between your subwoofers and midranges with real punch, so kick drums and bass guitar hit in the doors and not just the trunk. DV8 Shop is an authorized SoundQubed dealer.
It is built for high-output pro audio front stages and works well with a C Series 4-channel amp.
- Magnet is threaded for a 1" compression driver (coaxial-ready)
- Acoustically transparent, water-resistant dust cap
- Neodymium motor with 3" CCAW voice coil
- Water-resistant paper cone and aluminum basket
- 400W RMS / 800W max power handling
02 Tech specs
By the numbers
RMS Power 01
400W
Continuous rating
Peak Power 02
800W
Short-burst rating
Xmax 03
8.6mm
One-way excursion
Sensitivity 04
92dB
Efficiency
Excursion
Scale 0 to 12mmXMAX 8.6MM
- RMS Power
- 400W
- Max Power
- 800W
- Impedance
- 4 Ohm
- Terminals
- 10 gauge push terminals
- Frequency Response
- 69Hz – 6,000Hz
- Sensitivity (1W/1m)
- 92 dB
- Fs
- 69 Hz
- Re
- 3.6 Ohm
- Qms
- 6.18
- Qes
- 0.39
- Qts
- 0.37
- BL
- 10 T·m
- Xmax
- 8.6mm
- Voice Coil Diameter
- 3" / 75.5mm
- Magnet
- Neodymium
- Cone
- Water-resistant paper
- Dust Cap
- Acoustically transparent non-woven cloth, water resistant
- Voice Coil Material
- CCAW
- Basket
- Aluminum
- Size
- 8"
- Overall Diameter
- 8.4"
- Cutout Diameter
- 7.28"
- Depth
- 4.7"
- Mounting Depth
- 108mm
- Net Weight
- 4.6 kg / 10.14 lb
- Weight
- 6 lbs
- Dimensions
- 10 × 10 × 10 in
- Brand
- SoundQubed
- Model
- HDCMB084
- Type
- Midbass (coaxial-ready)
- EBP
- 186
- Diagonal Screw Hole
- 7.8"
