SoundQubed Q Series Q4-150AB v2 Class A/B 4 Channel Amplifier SQ-Q4-150
$699.95
Lease for as low as $31.63/week. Apply Now
The SoundQubed Q4-150AB v2 is a Class A/B 4-channel amplifier rated at 150W x 4 at 4 ohms, 220W x 4 at 2 ohms and 440W x 2 bridged.
- RMS Power @ 4 Ohm (14.4V): 150W x 4
- RMS Power @ 2 Ohm (14.4V): 220W x 4
- RMS Power @ 4 Ohm Bridged (14.4V): 440W x 2
- Frequency Response: 20Hz – 30kHz
The details
Product Overview
SoundQubed Q Series Q4-150AB v2 Class A/B 4 Channel Amplifier – The SoundQubed Q4-150AB v2 is a Class A/B 4-channel amplifier rated at 150W x 4 at 4 ohms, 220W x 4 at 2 ohms and 440W x 2 bridged. DV8 Shop is an authorized SoundQubed dealer.
Class A/B output keeps the sound natural, and the variable high- and low-pass filters can be used together as a band-pass, so one amp can run your mids, highs and even a subwoofer.
Bass boost up to 18 dB at 45Hz, a remote gain knob with clip indicator, four-way protection circuits and MOSFET switching are all included. It is 2-ohm stable in stereo and 4-ohm stable bridged.
- Class A/B 4-channel: run mids, highs and a sub from one amp
- Variable high- and low-pass filters, usable as band-pass
- Bass boost and remote gain knob with clip indicator
- 2 ohm stable stereo, 4 ohm bridged
- Four-way protection and MOSFET switching
By the numbers
- Class
- Class A/B
- Channels
- 4
- Working Voltage
- 9V – 16V
- Fuse Rating
- 120A (external)
- RMS Power @ 4 Ohm (14.4V)
- 150W x 4
- RMS Power @ 2 Ohm (14.4V)
- 220W x 4
- RMS Power @ 4 Ohm Bridged (14.4V)
- 440W x 2
- Damping Factor
- Greater than 200
- High-Pass Filter
- 20Hz – 5kHz
- Low-Pass Filter
- 50Hz – 5kHz
- Bass Boost
- 0 – 18dB @ 45Hz
- Frequency Response
- 20Hz – 30kHz
- Input Sensitivity
- 0.2V – 8V
- Dimensions (L x W x H)
- 22" x 9.5" x 2.63" (558.8 x 241.3 x 66.8mm)
- Weight
- 15 lbs
- Dimensions
- 28 × 12 × 5 in
- Brand
- SoundQubed
- Model
- Q4-150AB v2
- Signal to Noise Ratio
- 105dB
