DS18 DSP8.8BT 8-Channel In and 8-Channel Out Digital Sound Processor (DSP) with Bluetooth

$395.95

Lease for as low as $17.89/week. Apply Now

What is power without control?

RMS Power8V
Sensitivity0.2
01 Overview

The details

Product Overview

What is power without control? The DSP8.8BT, the latest addition to our line of Digital Sound Processors, gives listeners unchecked control over every facet of their audio system allowing easy and precise setting filtration. The DSP8.8BT allows you to access untapped power in your vehicle’s audio system, and give you the control needed to handle and achieve the quality of sound you desire.

With audio filtration settings accessible directly from your phone, getting the crispest audio quality possible has never been easier. This also gives users the option to save presets for certain songs or genres allowing for the perfect listening experience one hundred percent of the time.

The DSP8.8BT gives you access to a great number of tuning options that can be adjusted using the DSP8.8BT Application on the App Store or Google Play. Each input can be adjusted and summed. You can save your options and multiple presets for 8 channels, @6db/octave to 48db/octave, and visualization for your actual and simulated EQ curve.

Manual

02 Tech specs

By the numbers

DSP8.8BT · Manufacturer rated
RMS Power 01
8V
Continuous rating
Sensitivity 02
0.2
Efficiency

Working Voltage
9 – 16 VDC
Remote Input Voltage
9 – 16V
Remote Output Voltage
12.8V (0.5A)
Fuse Size
2 Amp
Input Impedance
20kΩ
Maximum Pre-Out Level (RMS)
8V
Pre-Out Impedance
200Ω
Crossover Slope
Selectable 6/12/18/24/36/48 dB/Oct
High / Low Level Input
Up to 8 channel
Low Level Output
Up to 8 Channel

THD + N
< 1%
Frequency Response
20Hz-20KHz (+/- 0.5dB)
Input Sensitivity
0.2 – 9V
Crossover Frequency
Variable HPF/LPF 20Hz to 20KHz

Signal to Noise Ratio @ A Weighted
>100dB
Length
6.37”/162 mm
Depth
3.6”/91.5 mm
Height
1.24”/31.7 mm

Equalization
31 Bands Parametric
Q Factor
Selectable 0.05 to 20
EQ Presets
Yes POP/Dance/Rock/Classic/Vocal/Bass
User Presets
Yes Basic / Advanced
DSP Speed
147 MIPS
DSP Precision
32-Bit
DSP Accumulators
72-Bit
Precision
24-Bit
Dynamic Range
108dB
Type
RCA (Female)
