DS18 IXS10.4S IXS Shallow-Mount 10″ Fiber Glass Subwoofer 600 Watts Rms SVC 4-Ohm

$229.95

Lease for as low as $10.39/week. Apply Now

RMS Power600W
Peak Power1,200W
Sensitivity84dB
SKU: IXS10.4S Categories: , , , Brand:
01 Overview

The details

Product Overview

Why we stock the DS18 IXS10.4S

The DS18 IXS10.4S is a shallow-mount 10″ subwoofer with a 2.5″ single 4 ohm voice coil. It handles 600 watts RMS (1,200 max) with 84 dB sensitivity and plays from 20Hz to 800Hz.

It needs just 3.66″ of mounting depth, ideal behind truck seats. Need a standard-depth 10? See the ZR10.4D. Want a smaller sub? Look at the ZXI8.4D.

Continuing the tradition of our very popular shallow mount subwoofers, we now have the IXS line which is the successor to our best selling SW slim subwoofer line. We took the SW line and made it even beefier for more bass. The IXS comes in both 10 and 12 inch. Also, they both have multiple voice coil options to get the most from your amplifier. These subs are perfect for the audiophile that wants a lot of bass but does not have much space for a full sized subwoofer. With these you can get that loud thump without having to sacrifice a lot of room.

Technical Details IXS10.4S Product Manual

Box Info

Key Features
  • IXS series was made to produce more bass than other shallow mount subs of it rating in ported or sealed boxes.
  • Large surround with flexible spider packs will help the CCA voice coil teach maximum Xmax producing full and deep bass with a up to spec box.
  • Shallow mount size will let you fit this sub in compact places and requires less box space than other subs its size giving you many options in which to place it.

02 Tech specs

By the numbers

IXS10.4S · Manufacturer rated
RMS Power 01
600W
Continuous rating
Peak Power 02
1,200W
Short-burst rating
Sensitivity 03
84dB
Efficiency
Size 04
10in
Nominal

RMS Power
600 Watts RMS
Impedance
4 Ohms
MAX Power
1200W

Sensitivity
84dB
Frequency Response
20-800 Hz

Voice coil size
2.5″
Magnet
Ferrite
Magnet Size
62oz
Frame
Aluminum
Cone
Paper
Dust Cap Material
Fiberglass
Surround
Stitched Rubber
Voice Coil Former Material
Aluminum

Size
10 inch
Mounting Depth
3.66″
Overall Diameter
10.63″
Overall Depth
4.13″
Front Mount Baffle Cutout
9.25″

Model
IXS10.4S
Type
Shallow Subwoofer
