DS18 IXS12.2D IXS Shallow-Mount 12″ Fiber Glass Subwoofer 800 Watts Rms DVC 2-Ohm

$249.95

Lease for as low as $11.3/week. Apply Now

RMS Power800W
Peak Power1,600W
Sensitivity84dB
SKU: IXS12.2D Categories: , , , Brand:
01 Overview

The details

Product Overview

Why we stock the DS18 IXS12.2D

The DS18 IXS12.2D is a shallow-mount 12″ subwoofer with a 2.5″ dual 2 ohm voice coil and a fiberglass dust cap. It handles 800 watts RMS (1,600 max) and plays from 20Hz to 600Hz.

It needs just 4.33″ of mounting depth and uses an aluminum basket. Need dual 4 ohm? Use the IXS12.4D. Smaller box? See the IXS10.2D.

DS18’s IXS Line of Shallow Mount Subwoofers are back with the IXS12.2D!

Built from our best selling SW slim subwoofer line the experts at DS18 took the SW line and made it even beefier for more bass.

This sub handles 800 W RMS and 1600 W MAX Power with a 84 dB sensitivity: high sensitivity for a shallow mount sub raising this model above and beyond the standard.

These Dual Voice Coil Subs are perfect for the listener looking to add more thump to their system.

Make the most of your space with the IXS12.2D!

Highlights

Great For

Technical Details Download IXS12.2D Product Manual

02 Tech specs

By the numbers

IXS12.2D · Manufacturer rated
RMS Power 01
800W
Continuous rating
Peak Power 02
1,600W
Short-burst rating
Sensitivity 03
84dB
Efficiency
Size 04
12in
Nominal

RMS Power
800 Watts RMS
Peak Power
1600 Watts Max
Impedance
2 Ohms
Nominal Impedance
2+2 ohms
RMS Power Handling
800W
MAX Power Handling
1600W
Recommended Lo Pass Crossover
80 Hz

Sensitivity
84 dB
Frequency Response
20 – 600 Hz
Sensitivity (1w/1m)
85 dB

Voice Coil Diameter
2.5″ / 63.5mm
Voice Coil Former Material
Aluminum
Winding Material
Copper
Cone Material
Paper
Dust Cap Material
Fiberglass
Surround Material
Stitched rubber
Basket Material
Aluminum
Basket Color/Finish
Corrugated Black
Magnet Material
Ferrite
Magnet Weight
62 Oz
Motor Diameter
6.3″ / 160 mm

Size
12 inch
Mounting Depth
4.33″ / 110 mm
Nominal Diameter
12” / 304.8mm
Displacement Volume
0.93L / 0.033ft3
Overall Diameter
12.6″ / 320 mm
Overall Depth
5″ / 129 mm
Front Mount Baffle Cutout
10.79″ / 274 mm
