01 Overview
The details
Product Overview
One marine head unit to rule them all! This marine head unit is full size, easy to use, stylish, and will also stand up to the rigorous punishment that all marine, golf cart, and off-road head unit go through. This powerful receiver features all the functions you need like BT, RCA outputs including subwoofer, USB linking and charging with remaining waterproof! This is the key to enjoying loud music with the highest quality for your boat, atv, or any vehicle that may see the water frequently.
Highlights
The MRX2 is DS18’s NEW all in one marine head unit that does it all!
Technical Details
MRX2 Product Manual
02 Tech specs
By the numbers
- Operating Voltage
- 10.5 -16 Volts
- Low Voltage Warning Alert
- YES (< 11V)
- Power Output RMS
- 4 x 15W @ 4ohm / 4 x 25W @ 2ohm
- RCA Pre-Out Voltage
- 4 Volts
- Output Impedance
- 500 ohm
- Audio Input
- L+R RCA (Aux Input)
- Frequency Response
- 20Hz to 20Khz
- FM Frequency Range
- 87.5 -107.9 MHz
- AM Frequency Range
- 530 -1710 KHz
- USB Capacity
- 64 Gb Max
- USB Charge Capacity
- 2.1Amp
- Waterproof Rating
- IPX6
- UV/Salt Protection
- YES
- Buttons
- Rubber + RGB Backlit (synced with LCM)
- Screen Panel
- Gorilla Glass with OCA Full Bonding
- Type
- Liquid Cristal Module
- Backlight
- 7 Colors Selectable (Auto / White / Red / Blue / Green / Purple / Cyan / Yellow
- Max
- 4 x 50W @ 2ohm
- Min Load
- 2 ohm Stable per Channel
- Equalizer
- 2 Bands (Bass 80Hz, Treble 12Khz)
- Presets
- YES (S-Bass / Vocal /Powerful / clarity)
- Subwoofer Control
- Level (-10 to +10)
- Audio Zones
- 2 Zones (Stereo + Subwoofer each)
- Independent Zone Control
- YES (Level/Tone)
- Weather Band
- 162.40 -162.55 MHz
- NOAA Weather Band
- YES Compatible
- Tuner Presets
- 18 FM / 12 AM / 6 WB
- Radio Data System
- YES (AF / TA / NEWS) Selectable
- Bluetooth Version
- 5.0 + EDR
- Audio Streaming
- A2DP
- USB Compatibility
- v2.0
- Audio Files Compatibility
- MP3, WMA
- Remote Control
- Wired 3.5mm Jack Input (Compatible with MXRC)
