Product Overview
The F4 is an exact duplicate of the very popular NXL-400.4 but now offered in flat mount configuration so you can keep a flush and clean look to your install. This 4 channel amplifier is the go to source to power all your DS18 marine speakers as all are an amazing fit with this sleek and powerful hydro amp.
Highlights
Technical Details NXL-F4 Product Manual
02 Tech specs
By the numbers
- Channels
- 4 Channel
- Amplifier Class
- Class D
- RMS Power
- 100 Watts RMS
- Impedance
- 4 Ohms
- Power Output @ 2 ohms
- 160Wx4CH
- Power Output @ 4 ohms
- 100Wx4CH
- Bridge Power Output @ 4 ohms
- 320Wx2CH
- Gain Range
- 0.2-6V
- Crossover Range
- 40 – 400Hz
- Bass Boost
- 0-18dB (Rear CHs)
- S/N Ratio Red 1W @ 4 ohms
- 90dB
- Frequency Range
- 20Hz – 20KHz
- Dimensions (MM)
- 238 x 135 x 41
- Forced Cooling System
- N/A
- Bass Remote Control
- N/A
- Topology Operation
- Full Range Digital
