DS18 PRO-HY6.4B PRO 6.5″ Coaxial Hybrid Mid-Range Water resistant Cone Loudspeaker with Built-in Driver 225 Watts Rms 4-Ohm
$114.95
The details
Product Overview
Why we stock the DS18 PRO-HY6.4B
The DS18 PRO-HY6.4B is a 6.5″ hybrid that mounts a compression driver on a water-resistant paper midrange. It handles 225 watts RMS (450 max) at 4 ohms with 96 dB sensitivity and plays from 100Hz to 20kHz.
One cutout gives you mids and highs, which is ideal on bikes and boats where space is tight. It needs 3.92″ of depth. Short on depth? Try the PRO-HY6.4MSL. Bigger opening? See the PRO-HY8.4B.
DS18’s Hybrid speakers give you the best of both worlds of mids and highs combined into one pro audio combination speaker.
This high powered pro audio mega speaker combines both a 6.5 high volume midrange speaker that also has a high wattage driver attached to the rear to give you a full range of frequencies at an amazingly loud volume.
These Hybrids have water resistant cones to help battle elements and are perfect for people looking to place a high wattage, high volume loudspeaker together without having to separately mount am additional driver.
Highlights
Technical Details PRO-HY6.4B Product Manual
By the numbers
Excursion
Scale 0 to 12mm- RMS Power
- 225 Watts RMS
- Impedance
- 4 Ohms
- Nominal Impedance
- 4 OHMS
- RMS Power Handling
- 225W
- MAX Power Handling
- 450W
- Recommended Hi Pass Crossover
- 120 Hz
- Frequency Response
- 100Hz-20KHz
- Sensitivity (1w/1m)
- 96dB
- Excursion (one way)
- Xmax 9.2 mm
- Free Air Resonance
- FS 199Hz
- BL Factor
- BL 4.769
- Xmax
- 9.2 mm
- Voice Coil Diameter
- 1” / 25.4 mm
- Voice Coil Former Material
- Kapton
- Winding Material
- CCAW
- Cone Material
- Water Resistant Paper
- Surround Material
- Cloth
- Basket Material
- Aluminum
- Basket Color/Finish
- Glossy Red
- Magnet Material
- Neodymium
- Magnet Weight
- 27 oz
- Voice Coil Inductance
- Le 4.22mH
- Cone Area
- Sd 145.26 Cm2
- Diaphragm Material
- Titanium
- Motor Diameter
- 4.65″ / 118 mm
- Size
- 6.5 inch
- Mounting Depth
- 3.92″ / 99.5 mm
- Nominal Diameter
- 6.5”
- Displacement volumen
- 0.047L
- Equivalent Volume
- Vas 2.211L
- Horn Diameter
- 3.26″
- Overall Diameter
- 6.85″ / 174 mm
- Overall Depth
- 4.28″ / 108.8 mm
- Front Mount Baffle Cutout
- 5.91″ / 150 mm
- Number of Ways
- 2
- Pair or Single
- Single
- Mechanical Factor
- Qms 5.96
- Electrical Factor
- Qes 1.524
- Total Factor
- Qts 1.214
- Mechanical Mass
- Mms 8.654g
- Mechanical Compliance
- Cms 73.792 mm/N
- DC Resistance
- Re 3.2 ohms
- Mechanical Mass w/o Air
- Mmd 6.7g
