DS18
DS18 XOHV Pre-Amp With Crossover For High Volt Amplifier
$95.95
Increase your systems signal to line-level with DS18’s XOHV !
- Frequency Response: 15Hz – 20KHz
- Bass Boost Frequency: 35~125Hz
01 Overview
The details
Product Overview
Increase your systems signal to line-level with DS18’s XOHV !
This 2-channel Pre-Amplifier has a built-in Crossover and selectable bass boost frequency with high volt input and output! The XOHV is designed to work in line with H-V amplifiers that usually don’t have these features equipped.
This Pre-Amplifier’s 2-Channel capabilities allow you to connect 2 or more amplifiers for insane results!
Increase your signal strength today with the XOHV!
02 Tech specs
By the numbers
- Low Level Input Range
- 1.6 – 9 Volts
- High Pass Filter Range
- 15Hz – 10KHz
- Low Pass Filter Range
- 50Hz – 20KHz
- Crossover Slope
- 12dB/Oct
- Bass Boost Range
- 0~18dB
- RCA Pre-Output Voltage at 12.8V
- 7 Volts
- RCA Pre-Output Voltage at 14.4V
- 9 Volts
- Number of Channels
- 2 (Left and Right)
- Power Input Terminal Size
- 14ga
- Fuse Size
- up to 1A (external)
- Remote Output
- Yes, (250mA)
- Input Ground Selector
- Yes, (Ground/200ohm/Insolated)
- Frequency Response
- 15Hz – 20KHz
- Total Harmonic Distortion (THD)
- 0.0002
- Bass Boost Frequency
- 35~125Hz
- Overall Length
- 5.9" / 150mm
- Overall Height
- 1.1" / 28mm
- Heatsink Length
- 4.86" / 123.5mm
- Gross Single Unit Weight
- 9.4oz
- Signal to Noise Ratio
- 100dB
- Stereo Signal Separation
- 85dB
- Led Indicator
- Power / Clip
- Tiffany RCA
- Yes, (Input and Output)
- Overall Wide
- 3.28" / 83.5mm
- Heatsink Wide
- 2.42" / 61.7mm
