DS18 ZR800.4D ZR 4-Channel Class D Amplifier 4 x 200 Watts Rms @ 4-ohm

$374.95

Lease for as low as $16.94/week. Apply Now

RMS Power1,280W
Peak Power3,600W
Weight5lb
SKU: ZR800.4D Categories: , , , Brand:
01 Overview

The details

.woocommerce-tabs ul.wc-tabs{display:none}.woocommerce-Tabs-panel–description>h2:first-child{display:none}.woocommerce-Tabs-panel–description>p:empty{display:none}.dv8-brand{color:#e4321f}.dv8-spec{–r:#e4321f;–rd:#a3160b;–ink:#111114;–ink2:#4a4544;–line:#e5e0df;–wash:#faf8f8;background:#fff;color:var(–ink);line-height:1.62;max-width:100%}.dv8-spec *{box-sizing:border-box}.dv8-spec__mono{font-family:ui-monospace,SFMono-Regular,’SF Mono’,Menlo,Consolas,monospace;font-variant-numeric:tabular-nums;letter-spacing:-.01em}.dv8-spec__sec{border-top:1px solid var(–line)}.dv8-spec__sec:last-of-type{border-bottom:1px solid var(–line)}.dv8-spec__sum{display:flex;align-items:center;gap:14px;cursor:pointer;list-style:none;user-select:none;padding:16px 2px}.dv8-spec__sum::-webkit-details-marker{display:none}.dv8-spec__sum::marker{content:”}.dv8-spec__sum:focus-visible{outline:2px solid var(–r);outline-offset:3px}.dv8-spec__sum:hover .dv8-spec__t{color:var(–rd)}.dv8-spec__t{font-size:12px;font-weight:800;letter-spacing:.15em;text-transform:uppercase;color:var(–r);transition:color .15s}.dv8-spec__lead{flex:1 1 auto;min-width:18px;border-bottom:1px dotted #bdb6b5;transform:translateY(-2px)}.dv8-spec__sign{flex:none;width:22px;height:22px;display:grid;place-items:center;font-size:17px;line-height:1;color:var(–r);transition:transform .2s ease}.dv8-spec__sign::after{content:’+’}.dv8-spec__sec[open] .dv8-spec__sign{transform:rotate(135deg)}.dv8-spec__body{padding:2px 2px 22px}.dv8-spec__lede{margin:0 0 13px;font-size:15.5px;color:var(–ink2);max-width:68ch}.dv8-spec__lede:last-child{margin-bottom:0}.dv8-spec__lede b,.dv8-spec__lede strong{color:var(–ink);font-weight:700}.dv8-spec__lede a{color:var(–r);text-decoration:underline;text-underline-offset:2px}.dv8-spec__feats{list-style:none;margin:0;padding:0;display:grid;gap:1px;background:var(–line);border:1px solid var(–line)}.dv8-spec__feat{background:#fff;padding:14px 18px;transition:background .18s,box-shadow .18s}.dv8-spec__feat:hover{background:var(–wash);box-shadow:inset 3px 0 0 var(–r)}.dv8-spec__feat b{display:block;font-size:13px;font-weight:750;margin-bottom:3px}.dv8-spec__feat span{font-size:14px;color:var(–ink2)}.dv8-spec__tw{overflow-x:auto;-webkit-overflow-scrolling:touch}.dv8-spec__table{width:100%;border-collapse:collapse;font-size:14px;min-width:380px}.dv8-spec__table thead th{background:linear-gradient(180deg,var(–r),var(–rd));color:#fff;text-align:left;padding:11px 18px;font-size:10.5px;font-weight:800;letter-spacing:.14em;text-transform:uppercase;white-space:nowrap;border:none}.dv8-spec__table tbody tr{border-bottom:1px solid var(–line);transition:background .16s,color .16s,transform .16s,box-shadow .16s}.dv8-spec__table tbody tr:nth-child(even){background:var(–wash)}.dv8-spec__table tbody tr:hover{background:linear-gradient(90deg,var(–r),var(–rd));color:#fff;transform:scale(1.012);box-shadow:0 4px 14px rgba(228,50,31,.32);position:relative;z-index:1}.dv8-spec__table tbody tr:hover td{color:#fff}.dv8-spec__table td{padding:10px 18px;vertical-align:top;border:none}.dv8-spec__k{font-weight:650;width:46%}.dv8-spec__v{font-size:13px;color:var(–ink2)}.dv8-spec__sls{list-style:none;margin:12px 0 0;padding:0;display:grid;gap:1px;background:var(–line);border:1px solid var(–line)}.dv8-spec__sl{background:#fff;padding:11px 18px;font-size:13.5px;transition:background .18s,box-shadow .18s}.dv8-spec__sl:hover{background:var(–wash);box-shadow:inset 3px 0 0 var(–r)}.dv8-spec__fits{list-style:none;margin:0;padding:0;display:grid;gap:10px}.dv8-spec__fit{border:1px solid var(–line);border-left:3px solid var(–r);padding:13px 17px;transition:background .18s}.dv8-spec__fit:hover{background:var(–wash)}.dv8-spec__fit b{display:block;font-size:13px;font-weight:750;margin-bottom:3px}.dv8-spec__fit span{font-size:14px;color:var(–ink2)}.dv8-spec__tip{margin:22px 0 0;background:#111114;color:#f0eeed;padding:18px 22px;border-left:4px solid var(–r)}.dv8-spec__tip b{display:block;font-size:10.5px;font-weight:800;letter-spacing:.15em;text-transform:uppercase;color:#ff6a53;margin-bottom:6px}.dv8-spec__tip span{font-size:14.5px}@media (max-width:560px){.dv8-spec__table tbody tr:hover{transform:none}.dv8-spec__table td{padding:9px 13px}}@media (prefers-reduced-motion:reduce){.dv8-spec *{transition:none!important}.dv8-spec__table tbody tr:hover{transform:none}}

Product Overview

DS18’s ZR series of amplifiers are guaranteed to supercharge your sound system to deliver brilliant sound and bulky bass frequencies.

The ZR series was designed to pump up the bass and help your speakers reach their maximum potential as a part of your sound system. These amps offer a surplus of tuning options: the ZR800.4D comes with Lowpass, and High Pass filters to help tune any song to your frequency.

The ZR800.4D is made to deliver 2 x 600 watts RMS @ 4-Ohms Bridge, 4 x 320 watts RMS @ 2-Ohms, and 4 x 200 watts RMS @ 4-Ohms giving you the perfect power for your bass.

Key Features

Great for:

Technical Details ZR800.4D Product Manual

02 Tech specs

By the numbers

ZR800.4D · Manufacturer rated
RMS Power 01
1,280W
Continuous rating
Peak Power 02
3,600W
Short-burst rating
Weight 03
5lb
Per unit

Channels
4 Channel
Amplifier Class
Digital
RMS Power
1280W (4 x 320W @ 2 ohm)
Impedance
4 Ohms
Total Watts (Peak)
3600W
RMS Power @ 4 ohm
4 x 200W
RMS Power @ 2 ohm
4 x 320W
RMS Power @ 4 ohm Bridge
2 x 600W
Damping Factor
160
Input Impedance
20K ohms
Channel Separation
60dB
Low Level Input Range
0.2-6V
High Level Input
No
X-Over Filter Range
40Hz-4KHz
Bass Boost Range
No
Infrasonic Filter
No
Number of Channels
4
Minimum Impedance
2 ohms (Stereo) / 4 ohms (Bridge)
Power Input Terminal Size
4 GA
Fuse Size
120A
DC Output Protection
Yes
Short Circuit Output Protection
Yes
Voltage Input Protection
Yes 16 Volts

Frequency Response
20Hz-20KHz
Efficiency @ 4ohm
88%
Total Harmonic Distortion (THD)
1.00%
Bass Boost Frequency
N/A

Body Color / Finish
Black Aluminum Brush

Overall Length
10″ / 254mm
Overall Height
2″ / 53mm
Heatsink Length
8.54″ / 217mm
Gross Single Unit Weight
5 LB

Signal to Noise Ratio
>90dB
Selectable X-Over
FULL/LPF/HPF
Phase Selector
No
Amplifier Type
Stereo Full Range
Led Indicator
clipping/protect/power
Remote Level Control
No
Cooling Fan
No
Voltmeter
No
Thermal Protection
Yes
Over-Load Protection
Yes
Clipping Protection
Yes
Overall Wide
7.24″ / 184mm
