Description
Product Overview
When you seek sound quality, it is best to have an idea of what to look for. Sensitivity, frequencies, woofer, tweeter, surround materials, and power handling are all important key factors. EXL SQ Coaxial Speaker brings it all with black glass fiber cone, advanced PEI dome tweeter, NEO magnets, die-cast baskets, 1″ BASV voice coils, 3 Ohms impedance strontium-magnets and machine finished basket surrounds.
Technical Details Download EXL-SQ5.25 Product Manual
Key Features
- Unique coaxial design with concave recessed tweeter.
- 3 ohms voice coil to help maximize power from amps.
- Glass fiber cone for great looks and high durability while keeping a high sensitivity.
Technical Data
| Specification | Details |
|---|---|
| Size | 25 inch |
| RMS Power | 80 Watts RMS |
| Impedance | 3 Ohms |
| Model: | EXL-SQ5.25 |
| Type: | Coaxial |
| Size: | 5.25″ |
| RMS Power: | 80W |
| MAX Power: | 340W |
| Frequency Response: | 100Hz – 22KHz |
| Impedance: | 3 ohms |
| Sensitivity: | 86dB |
| Surround: | Rubber Edge |
| Cone: | Black Glass Fiber |
| Magnet: | Strontium |
| Voice Coil Wire: | BASV |
| Voice Coil Size: | 1″ / 25.5mm |
| Magnet Weight: | 9 oz |
| Tweeter Size: | 0.8″ Neodymium PEI Dome |
