SoundQubed HDS Series 6×9 inch Pro Audio Coaxial Midrange 200W RMS 4 Ohm (Pair) SQ-HDSMRCX694
$299.95
The HDS 6×9-inch pro audio coaxial puts a high-output midrange and a tweeter in one speaker, so you get loud, full-range sound from a single mounting location.
- Nominal Impedance: 4 Ohm
- RMS Power Handling: 200W
- Sensitivity (1W/1m): 90 dB
- Frequency Range: 140Hz – 20kHz
- Sold As: Pair
RMS Power200W
Peak Power400W
Xmax1.0mm
Out of stock
01 Overview
The details
Product Overview
SoundQubed HDS Series 6×9 inch Pro Audio Coaxial Midrange 200W RMS 4 Ohm – The HDS 6×9-inch pro audio coaxial puts a high-output midrange and a tweeter in one speaker, so you get loud, full-range sound from a single mounting location. They are sold as a pair. DV8 Shop is an authorized SoundQubed dealer.
Rated at 200 watts RMS with a 4-ohm load, they are an easy upgrade over factory speakers and keep up with a strong 4-channel amp.
- 6×9" midrange and 1" neodymium tweeter in one 2-way pro audio coaxial
- 90 dB sensitivity, 140Hz – 20kHz
- 200W RMS / 400W max per speaker at 4 ohms
- 1.5" EICCW woofer voice coil
- Sold as a pair
02 Tech specs
By the numbers
RMS Power 01
200W
Continuous rating
Peak Power 02
400W
Short-burst rating
Xmax 03
1.0mm
One-way excursion
Sensitivity 04
90dB
Efficiency
Excursion
Scale 0 to 8mmXMAX 1MM
- Nominal Impedance
- 4 Ohm
- RMS Power Handling
- 200W
- Max Power Handling
- 400W
- Rms
- 7.0 kg/s
- Sensitivity (1W/1m)
- 90 dB
- Frequency Range
- 140Hz – 20kHz
- Fs
- 140 Hz
- Re
- 3.6 Ohm
- Qms
- 7.3
- Qes
- 1.4
- Qts
- 1.2
- Vas
- 2.7 L
- Cms
- 96.7 µm/N
- BL
- 5.4 T·m
- Sd
- 141 cm²
- Xmax
- 1.0mm
- Woofer Voice Coil
- 1.5" / 38mm EICCW on KSV former
- Cone Material
- Paper
- Surround Material
- Cloth
- Basket Material
- Steel
- Woofer Magnet
- Ferrite, Φ120 x 15mm
- Tweeter Voice Coil
- 1.0" / 25mm EICCW on Kapton bobbin
- Tweeter Magnet
- Neodymium
- Nominal Size
- 6×9" / 235 x 162mm
- Overall Size
- 235 x 162mm (9.25 x 6.38")
- Overall Depth
- 109mm (4.29")
- Front Mount Cutout
- 210 x 147mm (8.27 x 5.79")
- Mounting Depth
- 101mm (3.98")
- Net Weight (each)
- 1.7 kg / 3.75 lb
- Weight
- 9 lbs
- Dimensions
- 16 × 16 × 6 in
- Brand
- SoundQubed
- Model
- HDSMRCX694
- Type
- 2-way pro audio coaxial midrange
- Tweeter Diaphragm
- Al-Mg sheet
- Diagonal Screw Hole
- 170 x 115mm (6.69 x 4.53")
- Sold As
- Pair
